The S30A-6011DA belongs to the SICK S3000 Professional series of safety laser scanners. It uses 2D LiDAR time-of-flight technology for precise area monitoring. This model suits both mobile and stationary safeguarding tasks. Additionally, it provides a protective field range of 5.5 m and a radial warning field of 49 m.
The S30A-6011DA scanner operates with a pulsed laser diode at 905 nm. Its laser is Class 1 eye-safe under IEC 60825-1:2014. Specifically, the average optical power stays below 1 mW. The scanning angle reaches 190° with 0.25° or 0.5° angular resolution. Furthermore, the response time is ≤ 60 ms and can be configured from 60 ms to 120 ms.
Object resolution is configurable at 30 mm, 40 mm, 50 mm, 70 mm, or 150 mm. The systematic measurement error is typically ± 35 mm. For safety performance, the S30A-6011DA meets Type 3 per IEC 61496-1 and -3. Moreover, it achieves SIL 2 per IEC 61508, SILCL 2 per EN 62061, and PL d / Category 3 per EN ISO 13849-1.
This safety scanner provides one OSSD pair with PNP output at 250 mA. It also includes incremental encoder inputs for A/B phase signals. Besides, a safe EFI bus supports advanced device communication. The supply voltage is DC 24 V, with a range of 16.8 V to 28.8 V. In addition, the unit requires SELV or PELV safety extra-low voltage. Power consumption is typically 19 W without external output loads. The electrical connection uses a system plug with cable gland or M12 connectors.
The S30A-6011DA operates between -10 °C and +50 °C. Meanwhile, storage temperature ranges from -20 °C to +70 °C. The enclosure carries an IP65 rating under EN 60529. Its dimensions measure 155 mm x 185 mm x 160 mm. In addition, the housing uses aluminum die-cast with a polycarbonate optical hood. The device weighs approximately 3.3 kg.
The S30A-6011DA supports 8 field sets with up to 16 fields total. It also provides 16 monitoring cases for flexible safety logic. Furthermore, integrated incremental encoder inputs enable velocity-dependent adaptive protective field switching. Therefore, this scanner works well on automated guided vehicles and automated forklifts. It also suits mobile robotics and other dynamic safety applications.
First, mount the scanner on a stable bracket at the correct height. Next, connect the system plug with cable gland or M12 connectors. Then, wire the OSSD pair and encoder inputs to the control system. After that, configure the field sets and monitoring cases with SICK safety software. Finally, test the adaptive field switching before normal operation.
1x SICK S30A-6011DA Safety Laser Scanner
1x Mounting Bracket Set
1x Quick Start Guide
We ship all orders through Fedex, UPS, and DHL. Each unit is packed with protective foam for safe transport.
Q1: What is the protective field range of the S30A-6011DA?
A: The protective field range is 5.5 m, and the radial warning field reaches 49 m.
Q2: Which safety standards does this scanner meet?
A: It meets Type 3, SIL 2, SILCL 2, and PL d / Category 3 requirements.
Q3: What outputs does the S30A-6011DA provide?
A: It provides one OSSD pair (PNP, 250 mA) plus incremental encoder inputs and a safe EFI bus.
Q4: What makes this model suitable for AGV applications?
A: Integrated encoder inputs allow velocity-dependent adaptive protective field switching on moving vehicles.
Q5: What is the response time of this SICK safety scanner?
A: The response time is ≤ 60 ms and is configurable from 60 ms to 120 ms.
| Brand Name | |
| Model No. | S30A-6011DA |
| Product Type | Safety Laser Scanner |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
