Allen-Bradley 2094-BC07-M05-M Kinetix 6000 Module

## Product Introduction

The Allen-Bradley 2094-BC07-M05-M is a Kinetix 6000 Integrated Axis Module. This module serves as a converter module with an input voltage range of 324-528V rms 3-phase. It accepts an AC input voltage range of 360-480VAC. The module delivers a converter section output of 45kW and an inverter section output of 49 A. Its power dissipation spans 71-226 Watts. The module provides an output current of 45 Amperes and a nominal drive voltage of 360-480 Volts (3 Phase). It weighs 22.0 lbs (9.98 kg) and measures 7.7 x 11.9 x 16.7 in (196 x 302 x 426 mm).

## Technical Specifications Analysis

The 2094-BC07-M05-M operates within a temperature range of 32-122 F (0-50 C). Its voltage rating is 400/460VAC. The module has a continuous output current to bus of 67.7 A. It features a maximum bus capacitance of 17,915 Microfarads. The control input requires a fuse of FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) and a breaker of 1492-SPM2D060 or 1492-SPM1D150. The DC bus power fuse is a Bussmann Fuse: FWJ-125A Mersen: Bussmann Fuse. The module dissipates 71-226 Watts of power. It requires an installation clearance of 80 mm (3.10 in.) and a minimum enclosure depth of 302 mm (11.9 in.). The module is a Power Module Integrated Axis Module with a wattage of 22 kWatts.

## Application Scenarios & Usage Methods

This Integrated Axis Module is designed for multi-axis motion control applications in industrial automation. Use it in packaging, material handling, and assembly lines where precise speed and torque control are critical. It integrates seamlessly into Kinetix 6000 systems, reducing wiring and spare parts inventory. The module supports Safe Speed and other advanced safety features to protect personnel and equipment. Its modular design allows easy maintenance and future upgrades.

## Installation Guide & Packing List

Install the module in an enclosure with a minimum depth of 302 mm (11.9 in.). Maintain a bottom clearance of 80 mm (3.10 in.) for proper airflow. Ensure the enclosure meets the required cooling specifications. The packing list includes the 2094-BC07-M05-M module only. No additional accessories are included. Always follow the manufacturer's installation manual for detailed steps.

## Purchasing Advice

Verify your system's voltage requirements match the module's nominal drive voltage of 360-480VAC. Confirm the converter section output of 45kW and inverter section output of 49 A meet your load demands. Check the control input fuse and breaker specifications to ensure compatibility. This module is ideal for new installations or as a direct replacement for existing Kinetix 6000 systems.

## Repair & Maintenance Tips

Regularly inspect the module for dust accumulation and ensure proper ventilation. Monitor the operating temperature to stay within 32-122 F (0-50 C). Check the DC bus power fuse and control input fuses periodically. Replace any blown fuses with the specified types (FNQ-R-10 or FNQ-R-7.5). Keep the module's firmware updated to maintain optimal performance and safety features.

## FAQs

**Q: What is the input voltage range for the 2094-BC07-M05-M?**
A: The module accepts 324-528V rms 3-phase with an acceptable AC input voltage range of 360-480VAC.

**Q: What is the converter section output rating?**
A: The converter section output is 45kW.

**Q: What is the inverter section output rating?**
A: The inverter section output is 49 A.

**Q: What are the dimensions and weight of this module?**
A: Dimensions are 7.7 x 11.9 x 16.7 in (196 x 302 x 426 mm) and weight is 22.0 lbs (9.98 kg).

**Q: What safety features does this module include?**
A: It includes Safe Speed, Safe Maximum Speed, Safe Maximum Acceleration Monitoring, Safe Direction Monitoring, Zero Speed Monitoring, Enabling Switch Control, and Door Monitoring and Control.
