TSXDSY64T2K | Schneider Electric 64-Point Solid State Output Module

Name: TSXDSY64T2K | Schneider Electric 64-Point Solid State Output Module
Brand: N/A
Availability: InStock
Rating: 4.6 (16 reviews)

TSXDSY64T2K

Manufacturer: N/A
Series: N/A
Model Number: TSXDSY64T2K
Weight: N/A
Condition: In Stock
Availability: 100% Original Brand New
Product Origin: U.S.A
Shipping port: Xiamen
Warranty: 12 Month

TSXDSY64T2K: High-Density Output Control for Demanding Automation

When your TSX Micro PLC system needs to drive dozens of discrete loads without sacrificing panel space, the Schneider Electric TSXDSY64T2K delivers. This solid-state protected module packs 64 outputs into a standard format, giving you precise 24 V DC positive control for high-density automation tasks. As a consulting engineer, I recommend it when reliability and protection are non-negotiable.

Why the TSXDSY64T2K Belongs in Your Control Cabinet

The TSXDSY64T2K is a discrete output module from the Schneider Electric TSX Micro PLC range. It provides 64 solid-state protected outputs, each rated for 24 V DC positive systems per EN/IEC 61131-2 (19...30 V). Unlike mechanical relays, solid-state outputs mean no moving parts to wear out, so you get longer service life and faster response—1.2 ms—for high-speed switching applications.

Technical Specs That Matter

Output Count: 64 discrete outputs
Output Type: Solid state protected
Output Voltage: 24 V DC positive (EN/IEC 61131-2 19...30 V)
Current per Channel: ≤ 0.1 A
Current per Module: ≤ 5 A
Leakage Current: < 0.1 mA at 30 V
Response Time: 1.2 ms
Paralleling of Outputs: Yes, up to 3 maximum
Tungsten Load: ≤ 1.2 W
Residual Voltage: < 1.5 V
Load Impedance: > 220 W at state 1
Protection: Overvoltage (transil diode), reverse polarity (reverse mounted diode), overload and short-circuit (automatic trip)
Weight: 1.00 lbs (0.45 kg)

Protection That Prevents Downtime

Every output on the TSXDSY64T2K is safeguarded against overvoltage, reverse polarity, overload, and short circuits. The automatic trip function isolates faults before they cascade, protecting both the module and your connected devices. For engineers, this means fewer nuisance trips and more uptime.

Applications and Integration

The TSXDSY64T2K excels in applications requiring many discrete outputs: packaging lines, material handling, and assembly stations. It integrates directly with TSX Micro PLC systems. When wiring into your existing architecture, confirm backplane compatibility and connector requirements with your supplier. The module uses 4 HE-10 connectors and draws 155 mA at 5 V DC.

Selection and Support

Before ordering, verify your system voltage is 24 V DC positive and that your total load does not exceed 5 A per module. For paralleled outputs, never exceed three. SpareTech Plc offers expert technical selection support and genuine parts, fast shipping. Contact SpareTech Plc today for pricing and availability.

Reliability in Harsh Environments

The TSXDSY64T2K operates from 32…140 °F (0…60 °C) and tolerates 10…95 % relative humidity without condensation. With IP20 protection, it is suited for clean control cabinets. For maximum longevity, inspect connections periodically and ensure adequate ventilation.

FAQs

Q: Can I parallel outputs on the TSXDSY64T2K?

A: Yes, up to three outputs can be paralleled to increase current capacity.

Q: What is the maximum current per channel?

A: Each channel handles up to 0.1 A, with a module total of 5 A.

Q: Does this module protect against short circuits?

A: Yes, it features automatic trip on short-circuit and overload conditions.

Q: What is the response time?

A: The TSXDSY64T2K switches in 1.2 ms.

Q: Is the TSXDSY64T2K compatible with all TSX Micro PLCs?

A: It is designed for the TSX Micro PLC range. Please verify your specific CPU and rack compatibility with SpareTech Plc before ordering.

Figure 1: Front view of the Schneider Electric TSXDSY64T2K Solid state protected showing its physical design and enclosure.

Attention: The above product information is sourced from the internet and cannot be guaranteed to be authentic. For specific product parameters and prices, please contact SpareTech PLC professionals in a timely manner.

Brand Name
Model No.	TSXDSY64T2K
Product Type	Solid state protected
hasMerchantReturnPolicy	Adjust according to reality
Shippingdetails	Adjust according to reality

The TSXDSY64T2K is a solid-state protected module with 64 discrete outputs, specifically designed for 24 V DC positive systems within the Schneider Electric TSX Micro PLC range. It offers comprehensive protection features, including short-circuit, overload, and reverse polarity safeguards.Technical specifications for TSXDSY64T2K Manufacturer Schneider Electric Product Line TSX Micro PLCs Part Number TSXDSY64T2K EAN 3389110725582 Weight 1.00 lbs (0.45 kg) Discrete Output Number 64 Discrete Output Type Solid state protected Discrete Output Voltage 24 V DC positive (EN/IEC 61131-2 19...30 V) Current per Channel ≤ 0.1 A Current per Module ≤ 5 A Leakage Current < 0.1 mA at 30 V Tungsten Load ≤ 1.2 W Residual Voltage < 1.5 V Response Time 1.2 ms Paralleling of Outputs Yes, up to 3 maximum Output Overvoltage Protection By transil diode Reverse Polarity Protection Reverse mounted diode Output Overload Protection Automatic trip Short-Circuit Protection Automatic trip Load Impedance > 220 W at state 1Description The Schneider Electric TSXDSY64T2K module is a flexible solution for applications requiring multiple discrete outputs. Specifically designed for 24 V DC systems, it comprises 64 solid-state outputs, enabling precise control in various automation scenarios.With a maximum current rating of 0.1 A per output channel and an aggregate capacity of up to 5 A across the module, it is suitable for diverse operational requirements. Each output keeps leakage current below 0.1 mA at 30 V, ensuring efficient power usage. Maneuvering through switching demands, the module activates with a swift response time of 1.2 ms, maintaining operational integrity.Protection mechanisms enhance the TSXDSY64T2K's reliability. It features transit diodes for output overvoltage protection and includes reverse polarity safeguards through reverse-mounted diodes. Furthermore, short-circuit and overload situations trigger automatic trip mechanisms, ensuring safety and preventing damage to connected devices.In addition, the module supports paralleled outputs, allowing up to three outputs to work in unison, thus enhancing versatility in system design. It accommodates a maximum load of 1.2 W for applications requiring tungsten loads and ensures appropriate load impedance above 220 W. The residual voltage is kept under 1.5 V, ensuring minimal residual energy is present after switching.Range of Product Modicon Premium Automation platform Product or Component Type Discrete output module Discrete output number 64 Discrete output type Solid state protected Discrete output voltage 24 V DC positive EN/IEC 61131-2 19...30 V Complementary Current per channel 0.1 A Maximum current per module 5 A Maximum leakage current 0.1 mA 30 V Maximum tungsten load 1.2 W [Ures] residual voltage 1.5 V Response time 1.2 ms Paralleling of outputs Yes : 3 maximum Output overvoltage protection By transil diode Reverse polarity protection Reverse mounted diode Output overload protection Automatic trip Short-circuit protection Automatic trip Minimum load impedance 220 W at state 1 isalotion resistance > 10 MOhm 500 V Power dissipation (2.4 W + 0.1 W x No of outputs) Product Compatibility Dial and Power Marking CE Electrical connection 4 connectors HE-10 Current consumption 155 mA 5 V DC Module format Standard Net Weight 0.79 lb(US) (0.36 kg) Environment Dielectric strength 1500 V 50/60 Hz 60 s Standards UL 508 CSA C22.2 No 213 Class I Division 2 Group A CSA C22.2 No 213 Class I Division 2 Group C 93/68/EEC 89/336/EEC IEC 61131-2 CSA C22.2 No 142 CSA C22.2 No 213 Class I Division 2 Group B 92/31/EEC CSA C22.2 No 213 Class I Division 2 Group D 73/23/EEC Product Certifications RINA DNV BV ABS GL RMRS LR Ambient Air Temperature for Operation 32…140 °F (0…60 °C) Ambient Air Temperature for Storage -13…158 °F (-25…70 °C) Relative Humidity 10…95 % without condensation for operation 5…95 % without condensation for storage Operating altitude 0...6561.68 ft (0...2000 m) Protective treatment TC IP Degree of Protection IP20 Pollution degree 2 Ordering and shipping details Category US1PC2222558 Discount Schedule PC22 GTIN 3389110725582 Returnability No Packing Units Unit Type of Package 1 PCE Nbr. of units in pkg. 1 Package 1 Height 2.2 in (5.5 cm) Package 1 Width 7.09 in (18.0 cm) Package 1 Length 10.2 in (26.0 cm) Package weight(Lbs) 17.7 oz (503.0 g)
