TSXDSY32T2K | Schneider Electric 32-Point Solid State Output Module

Name: TSXDSY32T2K | Schneider Electric 32-Point Solid State Output Module
Brand: N/A
Availability: InStock
Rating: 4.6 (16 reviews)

TSXDSY32T2K

Manufacturer: N/A
Series: N/A
Model Number: TSXDSY32T2K
Weight: N/A
Condition: In Stock
Availability: 100% Original Brand New
Product Origin: U.S.A
Shipping port: Xiamen
Warranty: 12 Month

When a High-Density Output Card Fails Mid-Shift

A packaging line stalls when a single output card drops multiple solenoid valves at once. Maintenance teams need a drop-in replacement with the same footprint, voltage, and channel count — fast. The Schneider Electric TSXDSY32T2K answers that call: a 32-point discrete solid-state output module from the TSX Micro PLC series, built for dense 24 V DC control in demanding cabinets.

Figure 1: Front view of the Schneider Electric TSXDSY32T2K Solid state protected showing its physical design and enclosure.

What the TSXDSY32T2K Delivers

This module packs 32 discrete outputs into a standard-format housing. Each channel switches 24 V DC positive loads compliant with EN/IEC 61131-2 (19...30 V), at up to 0.1 A per channel and 3.2 A per module. Solid-state protected outputs cut wear compared with mechanical relays, while a 1.2 ms response time keeps high-speed sequencing accurate.

Key Technical Specifications

Discrete output count: 32, solid state protected
Output voltage: 24 V DC positive, EN/IEC 61131-2 (19...30 V)
Current per channel: 0.1 A; maximum per module: 3.2 A
Response time: 1.2 ms
Residual voltage: < 1.5 V; leakage current: < 0.1 mA at 30 V
Minimum load impedance: 220 Ω at state 1
Paralleling of outputs: yes, up to 3 maximum
Protection: transil diode overvoltage, reverse-mounted diode polarity, automatic trip on overload and short circuit
Electrical connection: 2 connectors HE-10
Current consumption: 140 mA at 5 V DC
Power dissipation: 1.6 W + 0.1 W x number of outputs
Insulation resistance: > 10 MOhm at 500 V
Dielectric strength: 1500 V, 50/60 Hz for 60 s
Ambient operation: 32…140 °F (0…60 °C); storage: -13…158 °F (-25…70 °C)
Relative humidity: 10…95 % without condensation (operation)
Operating altitude: 0...6561.68 ft (0...2000 m)
IP degree of protection: IP20; pollution degree 2
Net weight: 0.7 lb (0.3 kg)

Figure 2: Technical layout and connection details for the Schneider Electric TSXDSY32T2K Solid state protected.

Where It Fits on the Line

Angle: Replacement & Upgrade Guide. Three scenarios show the value. First, a bottling plant replaces a failed output card without rewiring — the HE-10 connectors and 24 V DC layout match the existing rack. Second, a material-handling OEM uses paralleling of up to three outputs to drive a higher-current load without adding hardware. Third, a panel builder standardizes on the TSX Micro PLC series, gaining automatic trip protection that reduces nuisance downtime from short circuits.

Installation and Setup Notes

Mount the module in a standard-format slot within the TSX Micro PLC rack. Wire outputs through the two HE-10 connectors, observing 24 V DC positive polarity. Keep cabinet temperature within 32…140 °F (0…60 °C) and humidity at 10…95 % without condensation. Respect IP20 — this module belongs inside a protected enclosure, not on an open panel. Verify load impedance stays above 220 Ω at state 1 to avoid leakage-related faults.

Maintenance and Long-Term Reliability

Solid-state outputs remove moving contacts, so routine attention focuses on the cabinet environment. Inspect connectors periodically for tightness, confirm airflow keeps ambient temperature inside the rated range, and check that pollution degree 2 conditions hold. The automatic trip on overload and short circuit protects the module between service visits. For a cost-effective spare strategy, keep one genuine TSXDSY32T2K on the shelf — in stock and ready to ship from SpareTech Plc.

Compatibility and Integration

The TSXDSY32T2K belongs to the TSX Micro PLC series and carries CE marking plus multiple marine and industrial certifications (ABS, RINA, GL, DNV, RMRS, LR, BV). It meets UL 508, CSA C22.2 No 142, and IEC 61131-2 standards. Integration Note: wiring into fieldbus networks may require an external gateway or connection module; confirm cables and gateways with your supplier before commissioning.

Buying Checklist

Before ordering, confirm your rack accepts standard-format TSX Micro modules, your loads run at 24 V DC positive within 19...30 V, and total module current stays at or below 3.2 A. Verify channel count and paralleling needs. Contact SpareTech Plc today for pricing and availability — expert technical selection support helps you match the right module the first time.

Frequently Asked Questions

Q: Can I parallel outputs on the TSXDSY32T2K?

A: Yes, up to 3 outputs maximum, useful for higher load capacity.

Q: What happens during a short circuit?

A: Automatic trip protection engages, reducing damage risk.

Q: What is the response time?

A: 1.2 ms, supporting responsive automated control.

Q: What connectors does it use?

A: Two HE-10 connectors for electrical connection.

Q: What is the operating temperature range?

A: 32…140 °F (0…60 °C).

Attention: The above product information is sourced from the internet and cannot be guaranteed to be authentic. For specific product parameters and prices, please contact SpareTech PLC professionals in a timely manner.

Brand Name
Model No.	TSXDSY32T2K
Product Type	Solid state protected
hasMerchantReturnPolicy	Adjust according to reality
Shippingdetails	Adjust according to reality

The TSXDSY32T2K from Schneider Electric is a versatile output module within the TSX Micro PLC series. This unit integrates 32 discrete solid-state outputs designed to operate efficiently within industrial environments. Each channel manages a current of up to 0.1 A, with a voltage specification of 24 V DC, ensuring compliance with the EN/IEC 61131-2 standards.Technical specifications for TSXDSY32T2K Manufacturer Schneider Electric Product Line TSX Micro PLCs Part Number TSXDSY32T2K EAN 3389110725575 Weight 1.00 lbs (0.45 kg) Tungsten Load ≤ 1.2 W Residual Voltage < 1.5 V Response Time 1.2 ms Paralleling of Outputs Yes, up to 3 maximum Discrete Output Count 32 outputs Output Overvoltage Protection By transil diode Discrete Output Type Solid state protected Discrete Output Voltage 24 V DC positive, compliant with EN/IEC 61131-2 standards Current per Channel ≤ 0.1 A Reverse Polarity Protection Reverse mounted diode Output Overload Protection Automatic trip Short-Circuit Protection Automatic trip Load Impedance > 220 Ω at state 1 Leakage Current < 0.1 mA at 30 V Current per Module ≤ 3.2 ADescription The TSXDSY32T2K model from Schneider Electric belongs to the TSX Micro PLC series. This output module is engineered with 32 discrete outputs that are solid-state protected, ensuring high reliability. It operates at a 24 V DC positive voltage, making it suitable for various automation applications while adhering to EN/IEC 61131-2 standards.Each output channel can handle a maximum load of 0.1 A, and the module can support a total current of up to 3.2 A. A notable feature is the low residual voltage at less than 1.5 V, which contributes to energy efficiency. The response time is quick, measured at 1.2 milliseconds, facilitating responsive control in automated systems.This output module allows for paralleling outputs, enabling users to combine up to three outputs for higher load capacity. A transit diode provides protection against overvoltage, while a reverse-mounted diode achieves reverse polarity protection. Additionally, the module features automatic trip mechanisms for both overload and short-circuit conditions, enhancing operational safety and reliability.This unit maintains a leakage of less than 0.1 mA at 30 V for applications that demand low leakage currents, supporting sensitive electronic systems. Moreover, the load impedance requirement exceeds 220 ohms at state 1, ensuring compatibility with various loads. This combination of features positions the TSXDSY32T2K as a robust choice for modern industrial control needs.Range of Product Modicon Premium Automation platform Product or Component Type Discrete output module Discrete output number 32 Discrete output type Solid state protected Discrete output voltage 24 V DC positive EN/IEC 61131-2 19...30 V Complementary Current per channel 0.1 A Maximum current per module 3.2 A Maximum leakage current 0.1 mA 30 V Maximum tungsten load 1.2 W [Ures] residual voltage 1.5 V Response time 1.2 ms Paralleling of outputs Yes : 3 maximum Output overvoltage protection By transil diode Reverse polarity protection Reverse mounted diode Output overload protection Automatic trip Short-circuit protection Automatic trip Minimum load impedance 220 W at state 1 isalotion resistance > 10 MOhm 500 V Power dissipation (1.6 W + 0.1 W x No of outputs) Product Compatibility Dial and Power Marking CE Electrical connection 2 connectors HE-10 Current consumption 140 mA 5 V DC Module format Standard Net Weight 0.7 lb(US) (0.3 kg) Environment Dielectric strength 1500 V 50/60 Hz 60 s Standards CSA C22.2 No 213 Class I Division 2 Group A CSA C22.2 No 213 Class I Division 2 Group B CSA C22.2 No 142 CSA C22.2 No 213 Class I Division 2 Group D 73/23/EEC CSA C22.2 No 213 Class I Division 2 Group C IEC 61131-2 89/336/EEC UL 508 92/31/EEC 93/68/EEC Product Certifications ABS RINA GL DNV RMRS LR BV Ambient Air Temperature for Operation 32…140 °F (0…60 °C) Ambient Air Temperature for Storage -13…158 °F (-25…70 °C) Relative Humidity 10…95 % without condensation for operation 5…95 % without condensation for storage Operating altitude 0...6561.68 ft (0...2000 m) Protective treatment TC IP Degree of Protection IP20 Pollution degree 2 Ordering and shipping details Category US1PC2222558 Discount Schedule PC22 GTIN 3389110725575 Returnability No Packing Units Unit Type of Package 1 PCE Nbr. of units in pkg. 1 Package 1 Height 2.2 in (5.5 cm) Package 1 Width 7.09 in (18.0 cm) Package 1 Length 10.2 in (26.0 cm) Package weight(Lbs) 14.7 oz (417.0 g)
