The TSXCANKCDF90T is a genuine Schneider Electric CANopen connector built for dependable bus termination. As part of the CANopen range, this connection accessory combines a 9-pin SUB-D female connector with an integrated line terminator — a single component that handles both physical connection and end-of-line signal termination.
Anyone who has chased intermittent CANopen faults knows the culprit is often a missing or poorly fitted terminator. The TSXCANKCDF90T removes that risk by packaging termination directly into the connector body. Its elbowed (90-degree) housing also eases installation in tight cabinet spaces where straight connectors foul doors or adjacent modules.
Each parameter matters in practice. The SUB-D 9 interface is the standard physical layer for CANopen networks, so this connector drops into existing cabling without adapters. The IP20 rating suits protected control cabinets and enclosures — the environment where most CANopen segments live. At just 0.046 kg, it adds negligible load to cable runs and panel strain relief.
Buyers often weigh three options for CANopen termination:
For teams standardizing on Schneider Electric CANopen hardware, the integrated approach reduces bill-of-materials complexity and speeds up fault-free startup.
The TSXCANKCDF90T serves any CANopen segment that needs a properly terminated endpoint. Typical scenarios include:
Because the connector is elbowed, it suits panels with shallow depth or dense module layouts — a common constraint in compact machinery.
Fit the TSXCANKCDF90T at the physical end of the CANopen bus segment. Confirm the bus layout before installation, and verify that termination is applied only at the two endpoints of the trunk. The elbowed housing should be oriented so the cable exits without sharp bends that stress the connector shell. Always follow the machine builder's network documentation during commissioning.
CANopen faults frequently trace back to termination and connector integrity. Periodic inspection of the connector seating, cable strain relief, and enclosure condition helps prevent intermittent communication errors. In cabinets exposed to vibration, check that the SUB-D coupling remains fully engaged. Keeping spare connectors on hand minimizes downtime when a terminator is damaged during service work.
Before ordering, confirm your bus type, connector gender, and termination requirement match this model. The TSXCANKCDF90T is a genuine Schneider Electric part, and SpareTech Plc supplies genuine parts, fast shipping, and expert selection support. Contact SpareTech Plc today for pricing and availability.
Please verify current lifecycle status and availability with SpareTech Plc before ordering.
