TSXCTY2A | Schneider Electric 2-Channel Counter Module

The TSXCTY2A component from Schneider Electric is an auxiliary output module designed for TSX Micro PLCs. This unit supports up to two channels with a counting frequency of 40 kHz and operates under the EN/IEC 61131 standards.Technical specifications for TSXCTY2A Manufacturer Schneider Electric Product Line TSX Micro PLCs Part Number TSXCTY2A EAN 3389110756975 Weight 1.00 lbs (0.45 kg) Electrical Circuit Type Auxiliary output conforming to EN/IEC 61131 Response Time < 2.5 ms sensor voltage at loss of 24 V auxiliary input (preset, enable, read) Channels 2 Counting Frequency 40 kHz Power Dissipation 4.5 to 6 W Cycle Time 5 ms Input Logic Current sink auxiliary input (preset, enable, read) Input Compatibility 2/3-wire proximity sensors (PNP/NPN), incremental encoder (10-30 V totem pole, 5 V DC RS422) Input Voltage 24 V (18 mA for sensors, 7 mA for auxiliary input, 18 mA for encoder) Voltage Limits <= 5.5 V for encoder, 19-30 V for sensors and auxiliary input Voltage State 1 >= 11 V for sensors and auxiliary input, >= 2.4 V for encoder Current State 1 >= 3.7 mA for encoder, >= 6 mA for sensors and auxiliary input Voltage State 0 <= 1.2 V for encoder, <= 5 V for sensors and auxiliary input Current State 0 <= 1 mA for encoder, <= 2 mA for sensors and auxiliary input Output Voltage 24 V DC Range of Product Modicon Premium Automation platform Product or Component Type Counter modules I/O modularity 2 channels Electrical circuit type Auxiliary output EN/IEC 61131 Complementary Counting frequency 40 kHz Power dissipation in W 4.5…6 W Cycle time 5 ms Discrete input logic Current sink auxiliary input (preset, enable and read) IEC 1131 Type 2 Resistive 2/3-wire proximity sensors PNP/NPN input IEC 1131 Type 2 Resistive encoder input Input logic Positive Input compatibility 2/3-wire proximity sensors PNP/NPN Incremental encoder 10...30 V totem pole Incremental encoder 5 V DC RS422 Input voltage 24 V 18 mA 2/3-wire proximity sensors PNP/NPN 24 V 7 mA auxiliary input (preset, enable and read) 5 V 18 mA encoder input Input voltage limits <= 5.5 V encoder input 19...30 V 2/3-wire proximity sensors PNP/NPN 19...30 V auxiliary input (preset, enable and read) Voltage state 1 guaranteed >= 11 V 2/3-wire proximity sensors PNP/NPN >= 11 V auxiliary input (preset, enable and read) >= 2.4 V encoder input Current state 1 guaranteed >= 3.7 mA encoder input) >= 6 mA 2/3-wire proximity sensors PNP/NPN) >= 6 mA auxiliary input (preset, enable and read)) Voltage state 0 guaranteed <= 1.2 V encoder input <= 5 V 2/3-wire proximity sensors PNP/NPN <= 5 V auxiliary input (preset, enable and read) Current state 0 guaranteed <= 1 mA encoder input) <= 2 mA 2/3-wire proximity sensors PNP/NPN) <= 2 mA auxiliary input (preset, enable and read)) Response time < 2.5 ms sensor voltage at loss of 24 V auxiliary input (preset, enable and read) Input impedance Encoder input > 270 Ohm at U = 2.4 V 2/3-wire proximity sensors PNP/NPN 1400 Ohm at Un Auxiliary input (preset, enable and read) 3400 Ohm at Un Encoder input 400 Ohm at Un Output voltage 24 V DC nominal output current 0.5 A Output voltage limits 19...30 V Maximum voltage drop <0.5 V at state 1 Output compatibility Positive logic DC inputs (resistance <= 15 kOhm) auxiliary output Maximum leakage current 0.1 mA Switching frequency < 0.6/LI² Hz on inductive load Output overload protection Thermal tripping via program or automatically Current limiter Output short-circuit protection Thermal tripping via program or automatically Current limiter Output overvoltage protection Zener diode Reverse polarity protection Reverse diode on supply Checks Sensor power supply Current consumption 280 mA 5 V DC 30 mA 24 V DC Module format Standard Local signalling 1 LED (green) for module operating (RUN) 1 LED (red) for external fault (I/O) 1 LED (red) for internal fault, module failure (ERR) 2 LEDs (green) for axis diagnostics available (CH.) Electrical connection 1 connector HE-10, 20 pins 2 connectors SUB-D 15 Net Weight 0.71 lb(US) (0.32 kg) Environment Protective treatment TC Ambient Air Temperature for Operation 32…140 °F (0…60 °C) Ambient Air Temperature for Storage -13…158 °F (-25…70 °C) Relative Humidity 5…95 % without condensation Operating altitude <= 6561.68 ft (2000 m) Ordering and shipping details Category US1PC2222558 Discount Schedule PC22 GTIN 3389110756975 Returnability No Packing Units Unit Type of Package 1 PCE Nbr. of units in pkg. 1 Package 1 Height 2.2 in (5.5 cm) Package 1 Width 7.09 in (18.0 cm) Package 1 Length 10.2 in (26.0 cm) Package weight(Lbs) 17.2 oz (489.0 g)Description The Schneider Electric TSXCTY2A is an auxiliary output module intended for use with TSX Micro PLCs. It adheres to the EN/IEC 61131 standards, making it suitable for various industrial applications. This module operates on two channels and can handle a counting frequency of 40 kHz.When the 24 V auxiliary power is interrupted, the response time is measured at under 2.5 ms, which impacts systems requiring prompt reactions. It features a cycle time of 5 ms, ensuring that it processes tasks efficiently.The module's input logic functions as a current sink auxiliary input. It is compatible with both 2 and 3-wire proximity sensors, such as PNP/NPN types, as well as incremental encoders running at a voltage of 10-30 V totem pole or 5 V DC RS422.Operating with a nominal input voltage of 24 V, current requirements include 18 mA for sensors, 7 mA for the auxiliary input, and 18 mA for the encoder. The input voltage limits are set at 19-30 V for sensors and auxiliary inputs, while the encoder operates at a limit of 5.5 V.For voltage state detection, it establishes a voltage state of 1 at greater than or equal to 11 V for sensors and auxiliary input and a minimum of 2.4 V for the encoder. Current states of 3.7 mA for the encoder, and 6 mA for the sensors and auxiliary inputs, signify active conditions. In contrast, voltage states of zero are recognized at 1.2 V for encoders or 5 V for sensors, with respective current states below 1 mA and 2 mA.This advanced module also provides an output voltage of 24 V DC to control connected devices effectively.
SpareTech PLC provides you with a PDF version of the instructions about N/A TSXCTY2A, where you can download the N/A TSXCTY2A manual PDF for free：
