Schneider BMXXBC008K Modicon X-bus Cable

Schneider BMXXBC008K Modicon X-bus Expansion Cable

Product Introduction Industrial automation architectures frequently connect adjacent rack baseplates to expand system I/O capacities across control panels. The BMXXBC008K X-bus expansion cable provides a dedicated high-speed communications link between adjacent rack chassis. Specially engineered within the Schneider Electric Modicon X80 ecosystem, this essential cable assembly guarantees signal integrity across multi-rack control systems.

Primary Technical Specifications

The BMXXBC008K features a precise functional length of 0.8 m designed specifically for short-distance rack connections. Furthermore, the cable assembly incorporates heavy-duty 9-pin SUB-D connectors on both ends for fast installation. Because this hardware functions strictly as a bus cable, it enables daisy-chaining multiple Modicon X80 rack bases together seamlessly.

Additionally, internal high-grade shielding guards high-frequency communication signals against surrounding electromagnetic interference inside electrical cabinets. Meanwhile, pre-molded strain relief boots protect connector terminations from mechanical fatigue caused by panel bending. Consequently, control engineers achieve reliable real-time backplane data transmission without experiencing intermittent network dropouts.

Physical and Environmental Attributes

Compact control panel layouts require flexible yet durable cabling solutions, so this lightweight cable assembly weighs only 0.18 kg. Moreover, the 0.8 m length eliminates excess wire clutter, maintaining neat cable routing along panel mounting rails. Durable outer jacketing shields internal conductors against ambient industrial contamination and physical abrasion during daily operations.

In addition, reliable signal transfer depends on mechanical stability under demanding cabinet operational conditions. The industrial-grade outer jacket tolerates standard operating temperature shifts typically found within sealed automation enclosures. Besides, sturdy threaded connector fasteners lock the assembly tightly against mating expansion sockets to withstand machine vibration.

Installation Guidelines

First, ensure that the controller backplane power is turned off before making physical cable connections. Next, locate the dedicated 9-pin SUB-D X-bus expansion ports on your Modicon X80 expansion modules. Then, align the BMXXBC008K connector pins carefully with the port interface on the first rack.

Furthermore, push the connector firmly into place and hand-tighten both captive securing screws completely. Next, route the flexible 0.8 m cable neatly to the adjacent rack expansion port without exceeding minimum bend radii. Finally, secure the second connector, restore system power, and verify backplane communications using status LEDs.

Packaging List 1 x BMXXBC008K Modicon X80 0.8 m X-bus Expansion Cable 1 x Protective Plastic Outer Packaging Sleeve 1 x Cable Handling and Specification Sheet

Shipping Information We ship all orders via fast international couriers including Fedex, UPS, and DHL.

FAQ

Q: What is the main function of the BMXXBC008K cable? A: It provides a high-speed X-bus connection for daisy-chaining multiple Modicon X80 rack chassis together.

Q: What is the overall length and connector type of this expansion cable? A: The cable measures 0.8 m in length and features standard 9-pin SUB-D connectors on both ends.

Q: Which PLC controller platforms utilize the BMXXBC008K expansion cable? A: It serves as a shared backplane interconnect cable for Modicon M340 and M580 series automation systems.

Q: Is the BMXXBC008K a battery module or power cable? A: No, BC stands for Bus Cable, meaning it is exclusively a communications cable for rack expansion.

Q: What global courier options are available for delivering this item? A: All international orders ship safely using fast express couriers like Fedex, UPS, and DHL.
