Schneider BMXEIA0100 Modicon X80 Serial Module

Schneider BMXEIA0100 Modicon X80 RS232/485 Serial Module

Product Introduction

The Schneider Electric BMXEIA0100 belongs to the Modicon X80 series. This serial communication module adds one RS232/RS485 port to a controller. It supports Modbus RTU, Modbus ASCII, and character mode. Furthermore, the module handles point-to-point communication tasks. Therefore, it links the controller to printers, scales, barcode readers, and other serial devices. This unit shares the same I/O platform as the M340 and M580.

Technical Specifications

The BMXEIA0100 offers a single serial channel. Specifically, it includes one built-in port. That port supports both RS232 and RS485 standards. The module runs Modbus RTU, Modbus ASCII, and character mode protocols. In addition, the baud rate ranges from 0.3 to 19.2 Kbps. Meanwhile, the module occupies one slot on the X-bus backplane. This compact footprint saves rack space in dense cabinets.

Electrical Parameters

Supply voltage for the BMXEIA0100 is 24 V DC. The backplane delivers this power directly. Power consumption reaches 1.7 W. Besides, bus current draw is 70 mA at 24 V DC. These values help engineers plan power budgets. The low current demand suits dense rack configurations. Therefore, the module runs cool and efficient.

Mechanical and Environmental Data

The module measures 100 × 28 × 93 mm. It weighs only 0.15 kg. The housing carries an IP20 protection rating. Operating temperature ranges from 0°C to +60°C. Storage temperature spans -25°C to +70°C. Relative humidity stays between 5% and 95%. However, condensation must not occur. These ratings suit standard control cabinets. They also fit many factory floor environments.

Installation Guide

First, verify the X-bus backplane has an open slot. Next, align the BMXEIA0100 with the slot guides. Then slide the module firmly into place. After that, tighten the retaining screw. The backplane supplies 24 V DC power automatically. No external wiring is needed for supply. For serial connections, use the front port. Specifically, choose RS232 or RS485 mode. After that, set the baud rate between 0.3 and 19.2 Kbps. Finally, configure Modbus RTU, ASCII, or character mode in your software. The module is now ready for point-to-point communication.

Packaging List

• 1 × Schneider BMXEIA0100 Modicon X80 Serial Module

• 1 × Original Box

• 1 × Protective Foam Insert

Shipping methods include Fedex, UPS, and DHL.

FAQ

Q1: What is the main function of the BMXEIA0100?
A: It adds one serial channel to a Modicon X80 controller. The unit supports point-to-point communication with serial field devices. It works with M340 and M580 platforms.

Q2: Which protocols does this module support?
A: The BMXEIA0100 supports Modbus RTU, Modbus ASCII, and character mode. You can select the mode through software configuration.

Q3: What is the supported baud rate range?
A: The baud rate ranges from 0.3 to 19.2 Kbps. This range covers most industrial serial devices. You can set it in the programming software.

Q4: How much power does the module consume?
A: Power consumption is 1.7 W. Bus current draw is 70 mA at 24 V DC. The backplane provides all needed power.

Q5: What shipping options are available?
A: We ship via Fedex, UPS, and DHL. Each order includes the module, original box, and foam insert. Delivery times vary by destination.
