Schneider 170MCI02136 Modicon Momentum I/O Controller

Product Introduction

The Schneider Electric 170MCI02136 is a capable I/O controller for the Modicon Momentum automation platform. This module provides reliable control and communication functions for industrial systems. It supports the Modbus Plus protocol, which ensures seamless integration with existing networks. Additionally, its compact design allows easy placement in control cabinets or on panels.

This controller operates efficiently on a 5 V DC power supply. It includes a configuration port that uses RS-232 connectivity via a separate adapter. The 170MCI02136 handles digital I/O signals directly. For more complex applications, you can add analog I/O capabilities through optional expansion modules. Therefore, this flexibility makes it suitable for a wide range of control tasks.

Technical Specifications

The 170MCI02136 offers a solid set of technical features for industrial control. First, its communication capabilities rely on the Modbus Plus protocol, which is widely used in factory automation. Furthermore, the module includes flash memory and SRAM to store configuration data and process logic reliably. In addition, the RS-232 configuration port simplifies the initial setup process when you pair it with the appropriate adapter.

Here are the core technical parameters:

• Product Type: I/O Controller

• Communication Protocol: Modbus Plus

• Supply Voltage: 5 V DC

• Configuration Port: RS-232 (adapter required)

• Memory Type: Flash and SRAM

• Digital I/O Support: Yes

• Analog I/O Support: Optional via expansion

• RoHS Compliant: Yes

Environmental & Mechanical Specifications

The 170MCI02136 performs reliably in varied industrial environments. For instance, its operating temperature range extends from 0°C to 60°C, which covers most indoor control room conditions. Moreover, it can withstand storage temperatures from -40°C up to 85°C, making it resilient during transportation or off-season storage. Meanwhile, the module's RoHS compliance reflects its environmentally responsible manufacturing approach.

Regarding installation, this controller offers two mounting choices. You can mount it on a standard DIN rail inside a cabinet. Alternatively, you can attach it directly to a panel using screws. This dual-mounting capability provides flexibility for different system layouts. Consequently, the module's compact weight of just 0.28 kg simplifies handling and installation.

Configuration & Setup Guide

Setting up the 170MCI02136 is a manageable process for trained technicians. To begin, mount the controller securely on your chosen surface. Next, connect the 5 V DC power supply to the designated terminals. Then, link the configuration port to a PC using an RS-232 adapter for initial programming.

After configuration, connect the controller to your Modbus Plus network. The module will automatically start communicating with other devices on the network. Finally, verify the digital I/O connections to ensure proper signal flow. For analog expansion, simply attach the optional expansion modules to the side of the controller. Therefore, the entire installation process takes only a short time to complete.

Packaging List

When you order the 170MCI02136, your package will contain:

• 1 x Schneider Electric 170MCI02136 I/O Controller

• 1 x Quick start guide

Please be aware that certificates and warranty documents are not part of this physical package. The RS-232 adapter is available separately. We ship all orders using reliable global carriers like FedEx, UPS, or DHL.

Frequently Asked Questions (FAQ)

Q1: What communication protocols does the 170MCI02136 support?
This controller primarily supports Modbus and Modbus Plus protocols for network communication.

Q2: Can I use analog sensors with the 170MCI02136?
Yes, you can connect analog sensors by adding optional analog I/O expansion modules to the controller.

Q3: What power supply does the 170MCI02136 require?
The module needs a stable 5 V DC power source to operate correctly.

Q4: How do I configure the 170MCI02136 for first-time use?
You need an RS-232 adapter to connect the configuration port to a computer, then use the appropriate software to set parameters.

Q5: Is the 170MCI02136 suitable for outdoor installations?
It is rated for indoor use with an operating temperature of 0 to 60°C. For outdoor use, you should use an additional protective enclosure.
