Schneider 170AAO92100 Analog Output Module

Product Introduction

The Schneider Electric 170AAO92100 provides four high-precision analog outputs for the Modicon Momentum platform. This base module converts digital commands into accurate analog signals, which makes it ideal for process control applications. Its compact design and robust electrical features ensure reliable performance in demanding industrial environments.

Technical Specifications

The 170AAO92100 delivers four analog outputs using a full 16-bit signed data format, which ensures exceptional resolution and accuracy for your control loops. Each output updates in just 2 ms, giving you fast response times for dynamic processes. The module provides 500V AC isolation between the channels and ground for one minute, which enhances system safety and protects connected equipment. Additionally, it supports internal reverse polarity protection, so you can avoid damage from accidental wiring errors.

Power and Electrical Characteristics

This analog output base dissipates a maximum of 8.5 watts, which makes it energy-efficient for continuous operation. It runs on a standard 24V DC supply, matching the typical power infrastructure of most industrial control panels. The module also includes robust protection features that maintain stable performance even under varying load conditions.

Mechanical and Environmental Parameters

The Schneider 170AAO92100 measures approximately 4.9 x 1.9 x 5.6 inches (124.5 x 48.3 x 142.2 mm) and weighs only 0.23 kg, which makes it easy to handle and install. It operates reliably within a temperature range of 0°C to 60°C, covering most indoor industrial scenarios. For storage, it withstands extremes from -40°C to 85°C, giving you flexibility for spare parts inventory. Furthermore, this module tolerates relative humidity up to 95% non-condensing in both operating and storage conditions, making it suitable for humid environments.

Installation and Integration

Installing the 170AAO92100 is straightforward because it follows the standard Modicon Momentum base format. You simply mount it onto a DIN rail and connect it to the appropriate communication adapter or processor. The module integrates seamlessly with other Momentum components, allowing you to build scalable I/O systems. Its compact footprint saves valuable panel space while maintaining easy access for wiring and maintenance.

Typical Applications

You can deploy the 170AAO92100 in a wide range of process control and automation tasks. It works well for controlling actuators, valves, and variable frequency drives that require precise analog signals. Industries such as water treatment, material handling, and packaging frequently use this module for reliable output control. Its 16-bit resolution ensures fine-grained adjustments, which directly improves product quality and process stability.

Packaging and Delivery

Each unit of the 170AAO92100 ships individually in its original packaging. The package contains the analog output base module ready for installation.

Shipping Methods: Fedex, UPS, DHL

Frequently Asked Questions (FAQ)

1. What type of analog outputs does the 170AAO92100 provide?
   This module provides four analog outputs using a full 16-bit signed format for precise signal representation and control.

2. How fast does the 170AAO92100 update its outputs?
   It updates all output channels in just 2 ms, ensuring rapid response for time-sensitive control applications.

3. What isolation does this module offer?
   The 170AAO92100 provides 500V AC isolation between the channels and ground for one minute, which protects your system from electrical faults.

4. Can I use the 170AAO92100 in high-humidity environments?
   Yes, it operates and stores reliably at humidity levels up to 95% non-condensing, making it suitable for many industrial settings.

5. Does the 170AAO92100 protect against reverse polarity wiring?
   Yes, it includes internal reverse polarity protection, so you can avoid damage if you accidentally reverse the power supply connections.
