The GE Fanuc IC693BEM333 Remote FIP Interface Module serves as a dedicated communication gateway for the Series 90-30 PLC platform. This module allows the controller to exchange process data with analog, discrete, and special field devices via a Factory Instrumentation Protocol (FIP) bus. Consequently, it helps monitor and manage a wide variety of industrial machinery effectively. The IC693BEM333 module does not support RX3i systems, but it remains a robust choice for existing Series 90-30 installations. Its open-frame design requires installation inside a protected panel to ensure long-term reliability. With straightforward slot-based mounting and clear LED indicators, this interface simplifies network integration for plant engineers.
The GE Fanuc IC693BEM333 module delivers stable performance under standard industrial conditions. It operates with a fixed transmission speed of 1 MHz, which is sufficient for many FIP-based monitoring tasks. The unit includes two D-type, 9-pin serial ports located on the front panel. These ports support direct connections to FIP network cables. Additionally, the module provides four status LEDs labeled CD1, TEN1, CD2, and TEN2. These lights offer immediate visual feedback on carrier detection and transmission activity for each channel. Furthermore, the IC693BEM333 communicates exclusively through the FIP protocol, ensuring compatibility with legacy GE Fanuc field devices. Its IP20 rating confirms that the module is suitable for indoor panel mounting only. Please note that this interface is not compatible with the RX3i system architecture.
This module uses an open-frame construction, which means it does not have a sealed housing. Therefore, you must install it inside a control cabinet or enclosure. Specifically, the operating temperature range is 0°C to 60°C, while the storage temperature spans from -40°C to 85°C. Moreover, the relative humidity should remain between 5% and 95% (non-condensing) to prevent internal damage. The IC693BEM333 weighs approximately 0.65 kg, making it lightweight and easy to handle during installation. However, this module is not designed for outdoor use or for environments with excessive dust, high moisture, or corrosive gases. For maximum longevity, place the device in a climate-controlled panel. This practice reduces unplanned downtime and protects the module from premature aging.
Installing the GE Fanuc IC693BEM333 is a straightforward process, but you must follow several key precautions. First, always disconnect the electrical supply before inserting or removing the module. The IC693BEM333 does not support hot-swap operations. Next, locate an available slot in the Series 90-30 backplane. Remember that Slot 1 is reserved exclusively for the CPU module. Therefore, you can install this interface in any other slot, such as Slot 2, 3, or 4. After that, slide the module firmly into the chosen slot until it seats properly against the backplane connector. Secure it using the retaining screws provided. Meanwhile, connect the FIP network cables to the two front D-type ports. Finally, power up the system and observe the four LEDs. These indicators will help verify that both communication channels are active and transmitting correctly.
When you receive the GE Fanuc IC693BEM333 Remote FIP Interface Module, the package will include the following items:
GE Fanuc IC693BEM333 module (1 unit)
User manual (printed quick-start guide)
Mounting screws (2 pieces)
Protective dust caps for serial ports (2 pieces)
Please note that network cables, power supplies, and backplane connectors are not included. Additionally, no certificates or warranty documents are provided with the product package.
We ship all orders using reliable international carriers. Specifically, we offer FedEx, UPS, and DHL as our standard shipping options. Each module is securely packed in anti-static material and cushioned to prevent transit damage. Tracking numbers will be provided within 24 hours after dispatch. For urgent deliveries, we recommend selecting expedited services at checkout. Furthermore, we can arrange special packaging for bulk orders upon request.
Q1: Can I use the GE Fanuc IC693BEM333 with an RX3i system?
No. The IC693BEM333 is specifically designed for the Series 90-30 platform and does not support RX3i architectures.
Q2: What is the transmission speed of this module?
The module operates at a fixed speed of 1 MHz. This rate is predefined by the hardware and cannot be adjusted.
Q3: How many serial ports does the IC693BEM333 provide?
It provides two D-type, 9-pin serial ports. Each port corresponds to a separate communication channel with its own LED indicators.
Q4: Can I install this module while the PLC is powered on?
No. You must turn off all power before inserting or removing the IC693BEM333. Hot-swapping is not supported.
Q5: What environmental conditions are suitable for this module?
Install it indoors inside a clean, dry, and temperature-controlled panel. Avoid high humidity, dust, and direct sunlight. The IP20 rating confirms it is not weatherproof.
| Brand Name | |
| Model No. | IC693BEM333 |
| Product Type | Remote FIP Interface |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
