BMENOC0301C | Schneider Electric M580 Ethernet Communication Module

Name: BMENOC0301C | Schneider Electric M580 Ethernet Communication Module
Brand: N/A
Availability: InStock
Rating: 4.6 (16 reviews)

BMENOC0301C

Manufacturer: N/A
Series: N/A
Model Number: BMENOC0301C
Weight: N/A
Condition: In Stock
Availability: 100% Original Brand New
Product Origin: U.S.A
Shipping port: Xiamen
Warranty: 12 Month

Boost M580 Network Performance with the BMENOC0301C

Industrial networks demand reliable, high-speed communication. The BMENOC0301C from Schneider Electric delivers exactly that for Modicon M580 systems. As a dedicated communication module, it handles Ethernet traffic with three RJ45 ports and an embedded multiport switch, simplifying cabling and reducing hardware costs. This module fits BMEXBP... Ethernet + X-bus racks, supporting up to four modules per rack. It draws internal power directly from the rack, so no external supply is needed. Whether you are building a new control system or upgrading an existing one, this module provides the connectivity backbone your operation needs.

Figure 1: Front view of the Schneider Electric BMENOC0301C Communication module showing its physical design and enclosure.

Key Technical Specifications

Product compatibility: BMEXBP... Ethernet + X-bus rack
Maximum modules per rack: 4
Integrated connection: 3 Ethernet RJ45 10/100 Mbit/s double shielded twisted pair
Transmission support: Ethernet backplane
Communication services: Bandwidth management, FDR server, SNMP network administrator, Modbus TCP I/O Scanner and Messaging, Ethernet/IP I/O Scanner and Messaging, RSTP support, port mirroring, embedded multiport switch, web server
Current consumption: 900 mA at 3.3 V DC (product version >= 13); 1800 mA at 3.3 V DC (product version < 13)
Local signalling: RUN (green), ERR (red), ETH MS (green/red), Eth NS (green/red)
Dimensions: Width 1.3 in (32 mm), Height 4.08 in (103.7 mm), Length 3.4 in (86 mm)
Net weight: 0.4 lb (0.2 kg)
IP degree of protection: IP20
Protective treatment: Conformal coating
Ambient air temperature for operation: 32…140 °F (0…60 °C)
Product certifications: CE, UL, CSA, RCM, EAC, Merchant Navy, ATEX zone 2/22, IECEx zone 2/22
Standards: EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201, IACS E10, EN/IEC 61000-6-5, EN/IEC 61850-3, EN/IEC 60079-0

Why the BMENOC0301C Fits Your Operation

This module excels in demanding environments. Its conformal coating and IP20 rating protect against dust and moisture, while the wide operating temperature range suits most industrial settings. The embedded multiport switch lets you daisy-chain devices without extra hardware, cutting installation time and cost. RSTP support ensures fast network recovery if a link fails, minimizing downtime. For engineers managing Modbus TCP and Ethernet/IP networks, the dual I/O Scanner and Messaging capabilities provide seamless integration. The web server enables remote monitoring and diagnostics, so you can troubleshoot without being on-site.

Figure 2: Technical layout and connection details for the Schneider Electric BMENOC0301C Communication module.

Applications and Integration

Use the BMENOC0301C in manufacturing plants, water treatment facilities, or energy management systems. It connects PLCs, drives, and HMIs over Ethernet, supporting real-time data exchange. The module also works in hazardous locations, thanks to ATEX zone 2/22 and IECEx zone 2/22 certifications. When integrating into your network, remember that fieldbus connections may require an external gateway or connection module. Confirm cable and gateway compatibility with your supplier before installation.

Selection and Support

Before ordering, verify your rack type and firmware version to ensure compatibility. SpareTech Plc stocks genuine Schneider Electric modules ready for immediate dispatch. Our technical team can help you select the right components for your M580 system. Contact SpareTech Plc today for pricing and availability.

Frequently Asked Questions

Q: What is the current consumption of the BMENOC0301C?

A: It draws 900 mA at 3.3 V DC for product version >= 13, or 1800 mA at 3.3 V DC for versions < 13.

Q: How many Ethernet ports does this module have?

A: It has three Ethernet RJ45 10/100 Mbit/s ports with double shielded twisted pair.

Q: Can I use this module in hazardous areas?

A: Yes, it holds ATEX zone 2/22 and IECEx zone 2/22 certifications.

Q: What communication protocols are supported?

A: It supports Modbus TCP and Ethernet/IP I/O Scanner and Messaging, along with SNMP, RSTP, and port mirroring.

Q: What is the operating temperature range?

A: The module operates from 32…140 °F (0…60 °C).

Attention: The above product information is sourced from the internet and cannot be guaranteed to be authentic. For specific product parameters and prices, please contact SpareTech PLC professionals in a timely manner.

Brand Name
Model No.	BMENOC0301C
Product Type	Communication module
hasMerchantReturnPolicy	Adjust according to reality
Shippingdetails	Adjust according to reality

BMENOC0301C Main Range of Product Modicon M580 Product or Component Type Communication module Complementary Product compatibility BMEXBP... - Ethernet + X-bus rack Maximum number of modules per rack 4 Supply Internal power supply via rack Integrated connection type 3 Ethernet RJ45 10/100 Mbit/s double shielded twisted pair Transmission support medium Ethernet backplane Communication service Bandwidth management FDR server SNMP network administrator Modbus TCP I/O Scanner and Messaging Ethernet/IP I/O Scanner and Messaging RSTP support Port mirroring Embedded multiport switch Web server Basic Current consumption 900 mA 3.3 V DC for product version >= 13) 1800 mA 3.3 V DC for product version < 13) Local signalling 1 LED (green) for processor running (RUN) 1 LED (red) for processor or system fault (ERR) 1 LED (green/red) for ETH MS (Ethernet port configuration status) 1 LED (green/red) for Eth NS (Ethernet network status) Width 1.3 in (32 mm) Height 4.08 in (103.7 mm) Length 3.4 in (86 mm) Net Weight 0.4 lb(US) (0.2 kg) Environment IP Degree of Protection IP20 Protective treatment Conformal coating Ambient air temperature for operation 32…140 °F (0…60 °C) Marking CE Product certifications CE UL CSA RCM EAC Merchant Navy ATEX zone 2/22 IECEx zone 2/22 Standards EN/IEC 61131-2 EN/IEC 61010-2-201 UL 61010-2-201 CSA C22.2 No 61010-2-201 IACS E10 EN/IEC 61000-6-5, interface type 1 and type 2 EN/IEC 61850-3, location G EN/IEC 60079-0 Directives 2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility 2014/34/EU - ATEX directive Environmental characteristic Gas resistant class Gx ISA S71.04 Gas resistant class 3C4 IEC 60721-3-3 Dust resistant class 3S4 IEC 60721-3-3 Sand resistant class 3S4 IEC 60721-3-3 Salt resistant level 2 IEC 68252 Mold growth resistant class 3B2 IEC 60721-3-3 Fungal spore resistant class 3B2 IEC 60721-3-3 Hazardous location class I division 2 Ordering and shipping details Category US1PC3418160 Discount Schedule PC34 GTIN 3606480713910 Returnability Yes Country of origin FR Packing Units Unit Type of Package 1 PCE Nbr. of units in pkg. 1 Package 1 Height 2.17 in (5.500 cm) Package 1 Width 4.33 in (11.000 cm) Package 1 Length 4.65 in (11.800 cm) Package weight(Lbs) 9.277 oz (263.000 g) Unit Type of Package 2 S02 Number of Units in Package 2 15 Package 2 Height 5.91 in (15.000 cm) Package 2 Width 11.81 in (30.000 cm) Package 2 Length 15.75 in (40.000 cm) Package 2 Weight 9.480 lb(US) (4.300 kg)
