Schneider TM200C16R Logic Controller | M200 Relay CPU

Schneider TM200C16R Easy Modicon M200 Logic Controller

Product Introduction

The Schneider TM200C16R brings reliable control to your automation environment. This Easy Modicon M200 series logic controller delivers 16 discrete I/O points with a mix of regular, fast, and high‑speed inputs. It also includes 7 relay outputs rated at 2A each. With a wide supply range of 100‑240V AC, it fits global installations. You can use it for conveyor systems, packaging machines, or simple process control. Its compact size saves panel space, while the integrated communication ports simplify networking. Whether you need basic logic or advanced PID regulation, the TM200C16R offers a balanced feature set for cost‑effective automation.

Technical Specifications

The TM200C16R operates on a rated supply voltage of 100‑240V AC , with limits from 85 to 264V. It consumes between 51 and 63 VA at full load. The controller includes 8 discrete inputs: I8 is a regular input, I2 through I5 are fast inputs, and I0, I1, I6, I7 serve as high‑speed inputs. For outputs, it provides 7 relay channels, all normally open, supporting 24V DC or 220V AC loads at up to 2A per point.

Each input accepts 24V DC logic, with a guaranteed ON state at ≥15V and OFF state at ≤5V. Input current is 7 mA, and the impedance is 3.3 kΩ. The inputs comply with type 1 sink/source logic per EN/IEC 61131‑2. Response times vary by function: relay outputs switch in 10 ms (both on and off), fast inputs respond in 35 µs (on) and 100 µs (off), while high‑speed inputs are even faster at 5 µs. You can also configure input filtering at 0, 3, or 12 ms to reject noise.

For counting and positioning tasks, the TM200C16R supports high‑speed counting (HSC) modes on its fast inputs. These include quadrature (x1, x2, x4), pulse/direction, single phase, and CW/CCW, all at 100 kHz with 32‑bit resolution. The controller also features a built‑in adjustable PID regulator capable of handling up to 14 simultaneous loops, making it suitable for temperature or pressure control.

Memory includes 512 bytes of internal flash for program backup, storing up to 10,000 instructions. An optional 32 GB micro SD card expands data logging and recipe storage. The real‑time clock drifts ≤90 seconds per month at 25°C, and a BR2032 lithium battery preserves data for up to 3 years during power loss.

Communication and Connectivity

Connectivity is a strong point of the TM200C16R. It includes a USB mini B port for programming via SoMachine‑Network, running at 12 Mbit/s. For fieldbus communication, it offers two non‑isolated serial links: serial 1 with RS485, and serial 2 configurable for RS232 or RS485. An isolated RS485 interface is also available on serial 2. These support Modbus master/slave protocols in RTU or ASCII modes, with baud rates from 1.2 to 115.2 kbit/s. You can network up to 4 expansion modules , increasing total I/O to 64 discrete outputs (transistor) or 71 (relay).

Mechanical and Environmental Ratings

This controller is built for industrial environments. It carries an IP20 rating when the protective cover is fitted, protecting against solid objects larger than 12.5 mm. Operating temperature ranges from 0 to 55°C for horizontal mounting, with storage from -25 to 70°C. It withstands vibration of 3.5 mm at 5–8.4 Hz and 1 gn at 8.4–150 Hz on a symmetrical rail. Shock resistance is rated at 15 gn for 11 ms and 30 gn for 6 ms. Relative humidity can reach 95% without condensation, and the unit operates at altitudes up to 2000 meters.

Insulation is robust: 1780V AC between output and logic, between output groups, and between supply and logic. Input‑to‑logic insulation is 500V AC. The controller also includes a 24V DC sensor power supply at 250 mA, eliminating the need for an external supply for small sensors.

Installation and Mounting

Mount the TM200C16R on a standard DIN rail (TH35‑15 or TH35‑7.5 per IEC 60715) or on a panel using an optional fixing kit. Its dimensions are 90 mm (H) x 110 mm (W) x 70 mm (D). All I/O connections use removable screw terminal blocks, simplifying wiring and maintenance. The power supply connects via a 3‑terminal block, and serial links use 4‑terminal or 3‑terminal blocks.

For wiring, keep unshielded input cables under 50 meters, and use shielded cables for fast and high‑speed inputs within 10 meters. Output cables can run up to 150 meters unshielded. The controller meets CE, CSA, cULus, IACS E10, and RCM certifications, ensuring compliance with global standards.

Packaging List

• 1 x TM200C16R logic controller

• 1 x Removable screw terminal block for inputs

• 1 x Removable screw terminal block for relay outputs

• 1 x Removable screw terminal block (4 terminals) for serial link 1

• 1 x Removable screw terminal block (3 terminals) for AC power supply

• 1 x Protective cover (fitted)

• 1 x Quick start guide (printed)

Note: Micro SD card, programming cable, and mounting kit are optional and sold separately.

Shipping Information

We ship the TM200C16R worldwide via FedEx, UPS, or DHL. All orders are processed within 24 hours on business days. Tracking numbers are provided upon dispatch.

Frequently Asked Questions (FAQ)

1. What software do I need to program the TM200C16R?
You need Schneider Electric's SoMachine Basic or SoMachine-Network software. These platforms support ladder logic, FBD, and IL programming for the Easy Modicon M200 series.

2. Can the TM200C16R replace an older Modicon M100 controller?
Yes, in most cases. The TM200C16R offers more I/O points, faster inputs, and additional communication ports. However, you should verify your existing program's memory usage and I/O mapping before migration.

3. How do I wire the relay outputs for AC loads?
Connect the load between the COM terminal and the corresponding Q output. The relays are normally open and rated for 220V AC at 2A. Use proper snubber circuits for inductive loads to extend contact life.

4. Does the controller support real‑time clock and data logging?
Yes, it has a built‑in RTC with battery backup. Data logging is possible using the optional 32 GB micro SD card , which stores historical data and recipes.

5. What is the maximum expansion capability for this model?
You can add up to 4 I/O expansion modules. For relay output systems, the total discrete outputs can reach 71; for transistor output types, up to 64 outputs are supported.
