This section provides a comprehensive overview of the TM5SDO8TA discrete output module. It belongs to the Modicon TM5 range and serves as a reliable interface between your logic controller and field actuators. Specifically, this module delivers eight source-type transistor outputs, making it suitable for various automation tasks.
First, let us examine the core electrical characteristics of the TM5SDO8TA. The module operates with a nominal output voltage of 24V DC, with an acceptable limit range of 20.4V to 28.8V. Furthermore, each output channel supports a continuous current of 2A, while the total current per common output is limited to 8A. The peak output current can reach up to 12A, but this is subject to duty cycle limitations.
Moreover, the switching performance is noteworthy. The Schneider TM5SDO8TA achieves a maximum switching frequency of 500Hz when driving resistive loads. Its response time is remarkably fast, with a maximum of 300µs for both state transitions (from 0 to 1 and from 1 to 0). Consequently, this module is well-suited for high-speed control applications. Additionally, the leakage current when the output is switched off is a mere 5µA, which prevents unwanted activation of connected devices.
The TM5SDO8TA includes comprehensive built-in protection features to ensure system integrity. For instance, it provides short-circuit protection, overload protection, and reverse polarity protection for each channel. These safeguards significantly reduce the risk of damage from wiring errors or load faults. Meanwhile, local diagnostics are clearly indicated via on-board LEDs. Specifically, eight yellow LEDs display the status of each output channel, while one green and one red LED indicate the overall power supply status.
The module is built to operate in demanding industrial environments. It complies with several international standards, including IEC 61131-2 and UL 508. The operating temperature range varies based on installation orientation: 0°C to 60°C for horizontal mounting with derating, 0°C to 55°C without derating, and 0°C to 50°C for vertical mounting. Furthermore, the TM5SDO8TA boasts an IP20 protection rating and can withstand vibration of 3.5mm at 5-8.4Hz and 1gn at 8.4-150Hz on a DIN rail. Its shock resistance is rated at 15gn for 11ms. Finally, the module operates at altitudes up to 2000m and can be stored at altitudes up to 3000m.
Installing the Schneider TM5SDO8TA is a straightforward process. First, ensure the power supply is disconnected before beginning the installation. Then, mount the module onto a standard DIN rail inside your control cabinet. The module uses a 1-wire electrical connection for each output, simplifying wiring. Next, connect the 24V DC power supply to the appropriate terminals, paying close attention to polarity to avoid activating the reverse polarity protection. After wiring, secure all connections and restore power. Finally, verify the module's functionality by checking the green power LED and the yellow output status LEDs during your initial test cycle.
1 x Schneider Electric TM5SDO8TA Digital Output Module
1 x Quick Start Guide (multi-language)
1 x Wiring label sticker
All orders for the TM5SDO8TA are shipped using premium courier services such as FedEx, UPS, or DHL. This ensures fast and reliable delivery to your facility, with full tracking capabilities provided for your convenience.
1. Which controllers are compatible with the TM5SDO8TA module?
The TM5SDO8TA is fully compatible with the Modicon M258 and LMC058 logic controllers, as well as motion controllers within the same ecosystem.
2. What is the maximum current I can draw from a single output channel?
Each output channel on the Schneider TM5SDO8TA supports a continuous current of up to 2A, with a peak capability of 12A for short durations.
3. Does the module provide protection against wiring faults?
Yes, the TM5SDO8TA includes built-in short-circuit, overload, and reverse polarity protection to safeguard both the module and connected loads.
4. What is the typical response time of the outputs?
The output response time for the TM5SDO8TA is exceptionally fast, with a maximum of 300 microseconds for both turn-on and turn-off transitions.
5. How do I know if the module is functioning correctly?
You can easily monitor the TM5SDO8TA via its local LEDs: a green LED indicates power is present, while eight yellow LEDs show the real-time status of each individual output channel.
| Brand Name | |
| Model No. | TM5SDO8TA |
| Product Type | Discrete Output Module |
