Schneider 140NOE21100C Modicon Quantum TCP/IP Module
Product Introduction
The 140NOE21100C belongs to Schneider Electric’s Modicon Quantum series. This TCP/IP module provides one dedicated channel for network communication. You can use it to link PLC systems with industrial Ethernet. The module supports three main applications: material handling, packaging machinery, and textile equipment. It delivers stable machine control without complex setup.
Technical Specifications
140NOE21100C operates as a single-channel Ethernet interface. The manufacturer Schneider Electric designed it for Modicon Quantum controllers. This unit supports standard TCP/IP protocols. Therefore, it integrates easily into existing factory networks.
Key parameters include the following:
Operating temperature: 0 to 40 °C
Storage temperature: 0 to 50 °C
Max operating humidity: 80% RH non-condensing
Max storage humidity: 80% RH non-condensing
Max operating altitude: 1000 m
Max storage altitude: 1000 m
Additionally, the module requires a clean indoor environment. It cannot tolerate corrosive chemicals. The housing protects against dust but not water. Therefore, you must install it inside a control cabinet.
Mechanical and Environmental Limits
The 140NOE21100C works reliably under typical industrial conditions. For instance, the temperature range supports most production halls. Furthermore, the humidity limit prevents condensation issues. Meanwhile, the altitude restriction ensures stable network communication.
However, you should avoid placing this module near heat sources. Do not expose it to direct sunlight. Similarly, keep it away from vibration or shocks. The module does not include a fan. Hence, natural air circulation is sufficient.
Installation Guidelines
First, power off the Quantum rack before inserting 140NOE21100C. Next, align the module with the slot. Push it firmly until it locks. Then, connect the Ethernet cable to the RJ45 port. Finally, configure the IP address using Schneider’s programming software.
Specifically, use shielded twisted pair cables. The cable length should not exceed 100 meters. Moreover, ground the rack properly to avoid electromagnetic interference. After installation, check the LED indicators. A steady green light means the network link is active.
Packaging List
140NOE21100C TCP/IP module – 1 unit
Quick start guide – 1 copy
Ethernet connector cover – 1 piece
Mounting clip – preinstalled
FAQ
1. Can the 140NOE21100C work with other Modicon series?
Yes, it fits all Modicon Quantum racks. However, it does not support Modicon M340 or M580.
2. What happens if the operating temperature exceeds 40 °C?
The module may lose network connection. Long-term overheating can damage internal components. Therefore, keep it within the specified range.
3. Does this module support both TCP and UDP?
It supports TCP/IP only. For UDP applications, consider other Quantum communication modules.
4. How do I reset the 140NOE21100C to factory settings?
Use the configuration software to restore defaults. There is no physical reset button on the module.
