The Keyence IV3-H1 is a PC software package for Keyence vision sensors. It includes IV3-Navigator, IV2-Navigator, and IV-Navigator in one bundle. Therefore, one license covers three sensor families. The software connects to sensors through an Ethernet link at 1000BASE-T speed.
This package suits engineers who set up and maintain IV3, IV2, and IV series cameras. Specifically, it handles parameter setup, image monitoring, and tool configuration. Meanwhile, it replaces manual on-sensor programming with a larger PC interface. As a result, commissioning and troubleshooting become faster and clearer.
The IV3-H1 is a PC-based software product, not a hardware device. It supports the IV3 Series, IV2 Series, and IV Series vision sensors. The included applications are IV3-Navigator, IV2-Navigator, and IV-Navigator. Interface access relies on Ethernet at 1000BASE-T.
Communication protocols depend on the connected sensor. For instance, the linked camera may use EtherNet/IP, PROFINET, or TCP/IP. The software itself has no built-in ports and no expansion options. Additionally, it needs a compatible Windows PC to run.
First, install the software on a PC with a working Ethernet port. Next, connect the PC to the sensor through a standard Ethernet cable. Then, launch the matching Navigator application for your sensor series. After that, search for the sensor and load its current configuration.
Meanwhile, confirm that the PC and sensor share the same network subnet. Besides, close other tools that may occupy the network adapter. For stable performance, use a gigabit-capable switch or direct cable link. Finally, save the sensor settings once tuning is complete.
The Navigator interface offers live image display and parameter editing. Moreover, it supports tool setup for inspection, positioning, and sorting tasks. Users can save and reload configuration files for repeat jobs. In addition, the software helps compare settings across multiple sensors.
Because the IV3-H1 covers three sensor families, it reduces software clutter. Specifically, one installation serves IV3, IV2, and IV models. This simplifies spare-part planning and engineer training. Consequently, maintenance teams work with a single familiar tool.
1 x Keyence IV3-H1 Software License
1 x Installation Media
1 x Quick Start Guide
Shipping is available via Fedex, UPS, and DHL. Please contact us for lead time and freight quotes.
Q1: Which sensors does the IV3-H1 support?
A1: It supports the IV3 Series, IV2 Series, and IV Series vision sensors.
Q2: What software is included in this package?
A2: The package includes IV3-Navigator, IV2-Navigator, and IV-Navigator.
Q3: How does the PC connect to the sensor?
A3: It connects through Ethernet at 1000BASE-T using a standard network cable.
Q4: Does the IV3-H1 require any hardware module?
A4: No. The IV3-H1 is PC software only and needs no extra hardware module.
Q5: Can I configure multiple sensor models with one license?
A5: Yes. One license covers IV3, IV2, and IV series sensors through their Navigator tools.
| Brand Name | |
| Model No. | IV3-H1 |
| Product Type | PC Software |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
