Keyence IV-2000MA Long Range Vision Sensor

Keyence IV-2000MA Integrated Vision Sensor

Product Introduction

The IV-2000MA belongs to the Keyence IV Series of integrated vision sensors. This long-range monochrome model handles inspection tasks across 300 to 2,000 mm working distances. Its auto focus system removes manual adjustment work from the setup process. Furthermore, the built-in infrared LED illumination supports both pulse and DC lighting modes.

Technical Specifications

The Keyence IV-2000MA uses a 1/3 inch monochrome CMOS image sensor. It captures images at 752 (H) x 480 (V) pixels. The field of view changes with the installed distance. Specifically, at 300 mm the view measures 45 x 33 mm, while at 2,000 mm it expands to 300 x 225 mm.

This sensor provides 16 detection tools and one position adjustment tool. Besides shape detection, it supports color area and area tools. Users can store up to 32 programs through switch settings.

Communication and Electrical Data

For network connectivity, the IV-2000MA includes an M12 4-pin connector. It supports 100BASE-TX and 10BASE-T Ethernet. Moreover, the device works with FTP client, EtherNet/IP, and PROFINET protocols. Communication expansion is not available on this model.

The unit runs on 24 VDC +/-10% supply voltage. Power consumption stays at 0.6 A or less. Outputs use open collector type with NPN/PNP switching. N.O./N.C. modes are also selectable, with a maximum rating of 26.4 V and 50 mA. In addition, six inputs (IN1 to IN6) and four outputs (OUT1 to OUT4) are provided.

Mechanical and Environmental Parameters

The main unit case uses aluminium die-casting material. The packing is NBR, the front cover is acrylic, and the mounting adapter is POM. The sensor weighs approximately 270 g.

Operating temperature ranges from 0 to +50°C without freezing. Relative humidity should stay between 35 and 85% RH without condensation. The protection rating reaches IP67, except when a polarized filter attachment is mounted. Vibration resistance covers 10 to 55 Hz at 1.5 mm double amplitude. Shock resistance handles 500 m/s^2 three times in six directions.

Installation Guide

First, mount the sensor using the POM adapter at the desired distance. Next, connect the M12 4-pin connector to your network cable. Then, let the auto focus system lock onto the target automatically.

For lighting, choose pulse or DC mode based on your application speed. After that, configure up to 32 programs through the switch settings. Finally, verify input and output wiring before powering the 24 VDC supply.

Packaging List

• 1x Keyence IV-2000MA Vision Sensor

• 1x Mounting Adapter

• 1x M12 4-pin Connector

• 1x Quick Start Guide

FAQ

Q1: What is the working distance of the IV-2000MA?
A: The installed distance ranges from 300 to 2,000 mm. The view size changes accordingly from 45 x 33 mm to 300 x 225 mm.

Q2: Does the Keyence IV-2000MA support color inspection?
A: No, this model is monochrome. It handles shape detection, color area, and area tools using grayscale imaging.

Q3: How does auto focus benefit my application?
A: Auto focus removes manual adjustment work. It locks onto targets quickly across the full 300 to 2,000 mm range.

Q4: How many programs can the IV-2000MA store?
A: The sensor stores up to 32 programs via switch settings. It also includes 16 detection tools and one position adjustment tool.

Q5: What is the protection rating of the IV-2000MA?
A: The rating is IP67. However, this rating does not apply when a polarized filter attachment is mounted.
