Schneider Square D JDL36225 PowerPact J Breaker

## Schneider Electric Square D JDL36225 Molded Case Circuit Breaker

### Product Introduction
The Schneider Electric Square D JDL36225 is a robust molded case circuit breaker from the PowerPact J-Frame series. This unit mount breaker delivers reliable thermal magnetic protection for industrial power systems. With a current rating of 225 A and three poles, it handles demanding applications. The toggle actuator ensures clear manual operation. Copper lugs on line and load sides simplify wiring.

### Technical Specifications Analysis
This breaker operates at 600 VAC with a frequency rating of 50/60 Hz. It provides a short-circuit current rating of 14 kA. The continuous current rating is set at 80 percent. The JDL36225 uses thermal magnetic trip technology with adjustable trip time. Dimensions are 7.52 inches high, 4.09 inches wide, 0.98 inches long, and 3.39 inches deep. It weighs 5 lb. Wire size accommodates up to 350 KCMIL. The frame type is J Frame, and mounting is panel mount. The UPC code is 785901623175.

### Application Scenarios & Usage Methods
This circuit breaker is ideal for commercial and industrial power distribution panels. Use it for feeder protection in manufacturing plants, data centers, and large buildings. It protects motors, transformers, and other equipment from overloads and short circuits. The thermal magnetic mechanism responds to both sustained overcurrents and high fault currents. Install it in switchboards or panelboards rated for its voltage and current.

### Installation Guide & Packing List
Mount the JDL36225 on a panel using the provided mounting hardware. Connect line and load conductors to the copper lugs. Torque lugs to manufacturer specifications. Ensure proper clearance for heat dissipation. The packing list includes one circuit breaker. No additional accessories are included. Verify the breaker matches your system voltage and current requirements before installation.

### Purchasing Advice
When purchasing the JDL36225, confirm your system voltage is 600 VAC or less. Check that the available fault current does not exceed 14 kA. Verify the frame size and mounting type match your panel. This breaker is suitable for new installations or as a replacement for existing J-Frame units. Buy from authorized distributors to ensure genuine Schneider Electric products.

### Repair & Maintenance Tips
Periodically inspect the JDL36225 for signs of overheating or damage. Clean the exterior with a dry cloth. Test the toggle mechanism for smooth operation. Do not attempt to repair internal components; replace the breaker if it trips frequently or shows wear. Follow lockout/tagout procedures before any maintenance. Keep the area around the breaker free of dust and debris.

## FAQs

### What is the current rating of the JDL36225?
The current rating is 225 A.

### What voltage can this breaker handle?
It is rated for 600 VAC.

### How many poles does the JDL36225 have?
It has three poles.

### What is the short-circuit current rating?
The breaker has a 14 kA short-circuit current rating.

### What type of terminals does it use?
Line and load terminals are copper lugs.
