Allen-Bradley 1747-M15 SLC 500 Memory Adapter Module

Allen-Bradley 1747-M15 Memory Adapter Overview

The 1747-M15 is a dedicated memory adapter socket for the Allen‑Bradley SLC 500 controller family. Its primary function is to bridge the gap between a standard PROM programmer and the 1747-M13 flash memory module. Without this adapter, you cannot easily program or erase memory modules for your SLC processors. Therefore, this socket is an indispensable tool for maintenance engineers and system integrators who need to manage program backups efficiently. Additionally, it supports multiple SLC processor models, which adds to its versatility in mixed‑platform facilities.

Core Technical Specifications and Compatibility

The 1747-M15 adapter socket is designed for simplicity and reliability. It provides a standardized interface for programming and erasing memory modules in industrial environments.

• Memory Type Support: This adapter supports Flash and EEPROM memory types. Specifically, it is designed to accommodate the 1747-M13 memory module, which provides 64 kilobytes (64,000 words) of user memory.

• Processor Compatibility: The 1747-M15 is fully compatible with three major SLC processor families: the SLC 5/03, SLC 5/04, and SLC 5/05. This broad compatibility makes it a valuable asset for facilities that use various SLC models.

• Adapter Design: The socket measures approximately 6 x 6 x 3 inches. It features a zero insertion force (ZIF) socket on the side that connects to the PROM programmer. This design minimizes mechanical stress on both the adapter and the memory module.

• Series Requirement: For correct and safe operation, you must use the 1747-M15 Series B adapter with the 1747-M13. Using a Series A version can potentially damage the memory module.

Installation and Handling Guidelines

Handling the 1747-M15 requires careful attention to avoid damage from electrostatic discharge (ESD). This socket is sensitive and should be treated with the same precautions as other electronic components.

• ESD Precautions: The 1747-M15 is sensitive to static electricity. Therefore, always use proper grounding measures when handling it. This includes wearing a grounded wrist strap and working in an ESD‑free environment.

• Installation Procedure: To use the adapter, simply insert the 1747-M13 memory module into the adapter socket. Then, fit the assembled unit into the ZIF socket of your commercial PROM programmer. Ensure the programmer is powered off during installation.

• Physical Dimensions: The adapter has a compact design with approximate dimensions of 6 inches by 6 inches by 3 inches, and it weighs about 2 pounds. This makes it portable and easy to store when not in use.

Packaging and Logistics

Your order includes the adapter socket only. All items are packaged securely to prevent physical damage and static discharge during transit.

• Packaging List:

  • 1 x 1747-M15 SLC 500 Memory Adapter Socket

Shipping: We use FedEx, UPS, or DHL to provide fast, insured, and trackable global delivery.

Frequently Asked Questions (FAQ)

Q1: What is the primary use of the 1747-M15 adapter?
The 1747-M15 serves as an interface socket between a commercial PROM programmer and the 1747-M13 memory module. It allows you to program, erase, and manage the flash memory content for SLC 500 processors.

Q2: Which processors are compatible with the 1747-M15?
This adapter supports the SLC 5/03, SLC 5/04, and SLC 5/05 processors. It is specifically designed to work with the 1747-M13 memory module used by these CPUs.

Q3: Why is the Series B version of the 1747-M15 important?
You must use the 1747-M15 Series B adapter with the 1747-M13. The older Series A version is not fully compatible and can cause permanent damage to the memory module.

Q4: What precautions should I take when handling the 1747-M15?
The 1747-M15 is sensitive to electrostatic discharge. Always wear a grounded wrist strap and work in a static‑safe environment. Also, ensure the programmer is off when inserting or removing the adapter.

Q5: What are the physical dimensions and weight of the 1747-M15?
The adapter measures approximately 6 inches by 6 inches by 3 inches and weighs about 2 pounds. Its compact design makes it easy to transport and store.
