Schneider Electric iC60N 2P C63 Miniature Circuit Breaker: Technical Guide for Industrial Control Panel Integration
Product Introduction
The Schneider Electric iC60N 2P C63 belongs to the Acti9 iC60N series of miniature circuit breakers. Specifically, this two-pole device carries a 63A rating with C-curve tripping characteristics. In addition, it handles both AC and DC network applications. Meanwhile, the thermal-magnetic trip unit responds to overloads and short circuits respectively.
Core Value
Firstly, the iC60N 2P C63 provides dual protection against overload currents and short-circuit currents. Moreover, it serves as a disconnector for industrial isolation purposes. Besides, the VisiTrip system enables rapid identification of faulty outgoing circuits. Consequently, maintenance teams reduce downtime significantly. Furthermore, the VisiSafe system ensures enhanced circuit protection safety.
Technical Insights
The Schneider Electric iC60N 2P C63 features a magnetic trip threshold of 8 x In ±20%. Additionally, its breaking capacity reaches 10 kA at 380-415V AC according to IEC 60947-2. Meanwhile, at 220-240V AC the rating climbs to 20 kA. The device also supports DC applications up to 125V with 10 kA breaking capacity. Specifically, the C-curve characteristic accommodates loads with moderate inrush currents.
Installation & Maintenance
Firstly, mount the iC60N 2P C63 on a standard TH35-7.5 DIN rail. Moreover, ensure power isolation before any wiring work. In addition, use copper conductors sized appropriately for 63A service. Furthermore, tighten terminal screws to secure connections properly. Meanwhile, routine inspections should verify terminal integrity and operating mechanism function. Besides, after a trip event, clear the fault condition prior to re-closing.
Buyer's Guide FAQ
Q1: What does the C63 rating mean on the Schneider Electric iC60N 2P C63?
A1: The C63 rating indicates a 63A nominal current with C-curve tripping. Therefore, it tolerates moderate inrush currents from motors and transformers.
Q2: Can the iC60N 2P C63 operate in DC circuits?
A2: Yes, this device supports DC applications up to 125V. Moreover, it delivers 10 kA breaking capacity in such configurations.
Q3: What is the breaking capacity of the Schneider Electric iC60N 2P C63?
A3: It reaches 10 kA at 380-415V AC and 20 kA at 220-240V AC. Furthermore, these ratings comply with IEC 60947-2 standards.
Q4: How do I mount the iC60N 2P C63 in a control panel?
A4: Firstly, snap the breaker onto a TH35-7.5 DIN rail. In addition, verify secure engagement before energizing the circuit.
Q5: What maintenance does the Schneider Electric iC60N 2P C63 require?
A5: Routine checks should inspect terminals and the operating mechanism. Besides, always clear fault conditions before re-closing after a trip.
