The 170CPS11100 from Schneider Electric provides reliable power conversion for the Modicon Momentum automation platform. This adaptor accepts a wide input range of 120 to 230 V AC, which users can adjust via an internal jumper. It delivers a regulated 24 V DC output at 0.7 A, sufficient for powering connected I/O modules and processors. Furthermore, the unit incorporates a terminal strip connector for secure and straightforward wiring. Its built-in RUN LED offers immediate visual confirmation of normal operation. Therefore, this power supply serves as an essential component for any Momentum-based control system.
This section outlines the key electrical and operational parameters of the Schneider Electric 170CPS11100. The input voltage rating spans from 120 to 230 V AC, with adjustment made through a jumper selection. The output provides a stable 24 V DC with a nominal current rating of 0.7 A. Operating frequency ranges from 50 to 60 Hz, accommodating both European and North American mains supplies. The associated fuse ratings are 0.63 A for 120 V operation and 0.315 A for 230 V operation, ensuring proper overcurrent protection. Local signalling is managed by a single RUN LED indicator, which illuminates when the unit is functioning correctly. Electrical connections are made via a terminal strip connector, which simplifies field wiring and maintenance.
The 170CPS11100 demonstrates robust environmental tolerance suitable for industrial settings. Its operating ambient temperature ranges from 0°C to 60°C, while storage temperatures extend from -25°C to 70°C. Relative humidity tolerance spans 5% to 95% (non-condensing) , enabling deployment in diverse climate conditions. The operating altitude is limited to 2,000 metres (6,561 feet) above sea level, covering the majority of factory and plant installations. The unit weighs a mere 0.28 kg (0.61 lb) , facilitating easy mounting and reducing panel loading. Additionally, its compact form factor conserves valuable space within control enclosures.
Installing the 170CPS11100 requires attention to safety and proper configuration. First, verify that the input voltage selector jumper matches your local mains supply (120 V or 230 V). Next, mount the unit securely onto a DIN rail inside the control cabinet. Then, connect the AC input wires to the appropriate terminals on the strip connector, ensuring correct phase and neutral connections. After that, wire the DC output terminals to the downstream Momentum modules, observing correct polarity. Finally, apply power and confirm that the RUN LED illuminates steadily. For optimal performance, use properly sized conductors and ensure that the fuse ratings are not exceeded. Remember to keep AC and DC wiring separated to minimise electrical noise interference.
Your shipment of the 170CPS11100 includes the following items:
Power supply adaptor unit (1 pc)
Terminal strip connector (installed)
Installation instruction sheet (paper copy)
All orders for the Schneider Electric 170CPS11100 are dispatched using premium courier services. We primarily ship via Fedex, UPS, or DHL to ensure fast and traceable delivery. Consequently, you can expect your package within 3 to 5 business days for most international destinations. Each parcel is securely packaged to prevent damage during transit.
1. What input voltages does the 170CPS11100 support?
This adaptor accepts 120 V or 230 V AC input, selectable via an internal jumper.
2. What is the output rating of the 170CPS11100?
It provides a regulated 24 V DC output with a maximum current of 0.7 A.
3. How do I know if the 170CPS11100 is operating correctly?
A green RUN LED on the front panel illuminates when the unit is powered and functioning normally.
4. What type of connection does the 170CPS11100 use?
It employs a terminal strip connector for both AC input and DC output wiring.
5. What is the operating temperature range for the 170CPS11100?
The unit operates reliably between 0°C and 60°C in non-condensing environments.
| Brand Name | |
| Model No. | 170CPS11100 |
| Product Type | Power Supply Adaptor |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
