The 170ADM35015 module offers a balanced I/O solution for modern control systems. This discrete solid-state I/O module comes from the reputable Modicon Momentum product line. It integrates 16 input channels and 16 output channels on a single compact unit. Consequently, this design saves valuable space in your control cabinet. The Schneider 170ADM35015 handles both signal acquisition and actuator control efficiently. Its robust construction ensures consistent performance in demanding industrial settings.
The input section features 16 discrete channels. These channels conform strictly to the IEC 1131-2 Type 1 standard. Therefore, they guarantee compatibility with a wide range of sensors. The input voltage range spans from 3 to 30 V DC. This broad range accommodates various field devices. Furthermore, the inputs utilize negative logic, meaning they operate as sinking inputs. Each input requires a minimum current of ≥2.5 mA when in State 1. The response time measures 2.2 ms for 0 to 1 transitions. Meanwhile, the 1 to 0 transition takes 3.3 ms.
On the output side, this module provides 16 solid-state outputs. The nominal output voltage is 24 V DC, with a maximum of 30 V DC. Each output point delivers a continuous current of 0.5 A. Additionally, you can group these outputs for higher loads. Specifically, each group supports up to 4 A, and the total module output current reaches 8 A. The outputs employ negative logic, functioning as sourcing outputs. Their response time is remarkably fast, under <0.1 ms for both transitions. This speed makes the 170ADM35015 ideal for precise control tasks.
Safety and reliability remain paramount in this design. The Schneider 170ADM35015 provides electrical isolation of 500 V AC between output channels and the bus. This isolation protects the control system from potential faults. Moreover, the module maintains low power dissipation. Total power dissipation is limited to ≤8 W. This efficiency reduces heat generation within the cabinet. Consequently, it contributes to the overall longevity of the module and adjacent components.
The 170ADM35015 operates effectively across a range of temperatures. Its operating temperature spans from 0 to 60 °C. This range suits most factory floor environments. The module's solid-state design offers high immunity to vibration and shock. Therefore, it performs reliably in applications with mechanical movement. Always ensure adequate ventilation around the module. Proper airflow helps maintain optimal operating temperatures.
This I/O module excels in various automation scenarios. Its mixed input and output configuration proves useful for machine control. Specifically, the 170ADM35015 connects sensors and actuators directly to the Modicon Momentum bus. The negative logic configuration simplifies integration with existing sinking/sourcing devices. Furthermore, its fast output response supports high-speed applications. These applications include packaging machinery, material handling, and assembly lines.
We package each 170ADM35015 module with care. The packaging prevents electrostatic discharge and physical damage during transit. The package includes the main module unit. No additional accessories or mounting hardware are included. The lightweight design minimizes shipping expenses. We dispatch all orders promptly through trusted global couriers.
1 x 170ADM35015 Discrete Solid-State I/O Module
1 x Protective Anti-static Bag
All orders are shipped using premium courier services. Your module will be delivered via FedEx, UPS, or DHL. A tracking number will be emailed to you upon dispatch.
1. What is the input voltage range for the 170ADM35015?
The 170ADM35015 accepts input voltages ranging from 3 to 30 V DC, accommodating diverse sensor types.
2. How many outputs does the Schneider 170ADM35015 provide?
This Schneider module offers 16 discrete solid-state outputs, each capable of handling 0.5 A continuously.
3. What logic type does the 170ADM35015 use?
The 170ADM35015 employs negative logic, with sinking inputs and sourcing outputs for straightforward system integration.
4. What is the isolation voltage rating for this I/O module?
The isolation voltage between output channels and the bus is rated at 500 V AC for enhanced safety.
5. Which carriers do you use for shipping?
We ship the 170ADM35015 and all other items using FedEx, UPS, or DHL for reliable and fast delivery.
