The MTL5541 is a single-channel repeater power supply for intrinsic safety applications. It provides a fully-floating DC supply to power conventional 2 or 3-wire 4/20mA transmitters installed in hazardous locations. Additionally, this unit repeats the measured current in a separate floating circuit to drive a load in the safe area. For HART 2-wire transmitters, the MTL5541 enables bidirectional communication signals superimposed on the loop current. Therefore, this model offers a versatile and reliable isolation solution for critical process measurements.
The MTL5541 delivers precise and stable performance for demanding process control loops. Its technical design ensures signal integrity while maintaining operator safety.
The hazardous-area input accepts a signal range from 0 to 24mA, which includes over-range conditions. This unit provides a transmitter voltage of 16.5V at 20mA to ensure proper device operation. Meanwhile, the safe-area output mirrors this signal with a standard range of 4 to 20mA. Specifically, it supports an under/over-range capability from 0 to 24mA for diagnostic visibility.
For the standard MTLx541 configuration, the safe-area load resistance is 0 to 360Ω when operating at 24mA. At the nominal 20mA signal, this load range extends to 0 to 450Ω. Consequently, this flexibility allows the MTL5541 to accommodate various receiving instruments in the control room.
Transfer accuracy at 20°C is better than 15µA, which guarantees high-fidelity signal reproduction. Temperature drift remains below 0.8µA/°C, so stable performance persists across ambient temperature changes. Furthermore, the response time is exceptionally fast, settling to within 10% of the final value within 50µs.
Terminals 2 to 1 and 3 have safety parameters of Uo=28V, Io=93mA, and Po=651mW with Um=253V rms or dc. Terminals 1 to 3 are simple apparatus rated at ≤1.5V, ≤0.1A, and ≤25mW. Therefore, this design permits connection into any intrinsically safe loop with an open-circuit voltage below 28V without extra certification. Moreover, the MTL5541 has received assessment for IEC 61508 functional safety applications. It is SIL2 capable for a single device (HFT=0) and SIL3 capable when used in redundant configurations (HFT=1).
Maximum current consumption is 51mA at 24V with a 20mA signal. Power dissipation inside the unit is 0.7W at 24V dc. Additionally, safe-area circuit ripple stays below 50µA peak-to-peak, which prevents interference with sensitive measurement circuits.
This unit fully supports HART communication through terminals 1 and 2 only. As a result, this feature enables bi-directional digital communication for configuration, calibration, and diagnostics without interrupting the analog loop current.
The MTL5541 features a compact industrial design for DIN-rail mounting. A green LED indicator gives clear visual confirmation of power status. Moreover, this unit operates across a wide ambient temperature range. It is suitable for Zone 0, IIC, T4-6 hazardous areas when paired with certified transmitters. Likewise, it holds a rating for Division 1, Group A hazardous locations.
Proper installation ensures optimal safety and performance for the MTL5541. First, mount the unit securely on a standard DIN rail inside a suitable enclosure. Next, connect the hazardous-area transmitter to terminals 1, 2, and 3 according to the wiring diagram. Then, wire the safe-area load to the designated output terminals. Besides that, ensure the power supply voltage matches the specified range. Finally, verify all connections thoroughly before applying power. The green LED will illuminate to confirm normal operation.
Each shipment contains the following items in the package:
MTL5541 Repeater Power Supply (one unit)
Quick start installation guide
Terminal identification label set
Please inspect all contents upon receipt to ensure completeness.
We dispatch all orders using premium international courier services. Specifically, we ship exclusively via FedEx, UPS, and DHL to ensure fast and traceable delivery worldwide. For specific shipping timelines and rates to your region, please contact our sales team.
Can the MTL5541 power a 4-wire transmitter?
Yes, separately powered current sources like 4-wire transmitters can connect to the MTL5541. However, please note that HART communication will not operate in this configuration.
What is the maximum safe-area load for this unit?
The safe-area load resistance is 0 to 360Ω at 24mA and extends to 0 to 450Ω at 20mA. Therefore, this range accommodates most common receiving instruments.
Is the MTL5541 suitable for SIL-rated safety loops?
Absolutely. The MTL5541 has undergone assessment per IEC 61508. It is SIL2 capable as a single device and SIL3 capable in redundant configurations.
Does this model support HART communication?
Yes, HART communication is fully supported. For proper operation, you must connect the HART communicator or system to terminals 1 and 2 only.
What is the response time of the MTL5541?
The unit settles to within 10% of the final output value within 50µs. Hence, this rapid response makes it ideal for fast-changing process signals.
