Product Introduction
This PZ-G101CB sensor from Keyence provides reliable object detection for automated machinery. Its narrow view reflective design minimizes background interference. Additionally, the unit features a robust glass-fiber reinforced PBT housing for durability. Furthermore, the threaded M18 body simplifies mounting in tight spaces.
Technical Specifications
The PZ-G101CB operates on a supply voltage of 10 to 30 VDC. It consumes 34 mA or less of current. Specifically, the light source is a red LED with a spot diameter of approximately 5 mm at 100 mm. Moreover, response time is a quick 500 µs maximum. Users can select between LIGHT-ON and DARK-ON modes via a switch. The output is a chaotic open collector type, rated for 30 V and 100 mA maximum.
Mechanical and Environmental Parameters
The sensor features an M18 threaded body for secure mounting. The front M18 part has a maximum tightening torque of 1.0 N·m. Meanwhile, the side slotted hole allows for an alternative mounting method with 0.5 N·m torque. The operating temperature range is -20 to +55 °C. Besides, protection ratings include IP67 and IP69K, ensuring resistance to dust and high-pressure washdowns. The PZ-G101CB also withstands shock of 1,000 m/s² and vibration from 10 to 55 Hz.
Installation Guide
First, mount the sensor using the M18 nut. Ensure the front threads are tightened to the specified torque. Next, connect the M12 connector cable, which is sold separately. After that, adjust the 1-turn trimmer to set the sensitivity for your specific application. Finally, select the desired output mode using the operation switch. Therefore, verify the stable operation indicator is green for reliable performance.
Packaging List
PZ-G101CB Sensor Unit
M18 Nut (1 piece)
Instruction Manual
FAQ
Q: Is the M12 cable included with this sensor?
A: No, the M12 connector cable is sold separately. Therefore, you must order a compatible cable for installation.
Q: What is the maximum detection distance for this model?
A: The PZ-G101CB offers a maximum detecting distance of 200 mm for standard targets. Additionally, it performs well with small objects at close range.
Q: Does this sensor support both NPN and PNP wiring?
A: Yes, it features a chaotic output that supports both NPN and PNP configurations automatically. Moreover, no external adapter is required for either wiring type.
Q: What is the price and shipping method for this item?
A: The price is RMB 1,350.00. We ship via Fedex, UPS, and DHL for fast delivery. Furthermore, orders are processed within one business day.
Q: Can this sensor be used in wet environments?
A: Yes, it carries an IP69K rating, making it suitable for high-pressure cleaning and wet conditions. Besides, the PAR lens cover resists water and dust ingress.
