The IS210AEBIH3BEC printed circuit board functions as an Alternative Energy Bridge Interface. GE designed this board for the Mark VIe Wind Turbine Control Series. Its main job is to manage bridge communication in alternative energy setups. Additionally, this version includes a special assembly type. It also uses a conformal coating to protect all components.
This board carries the functional acronym AEBI. The IS210AEBIH3BEC operates with a functional revision of B. Its assembly variant is number three. The H3 in its name indicates group three series classification. Moreover, the coating style is standard conformal coating. This coating covers every hardware surface. It is thinner than normal coatings but more effective. Therefore, this model resists moisture and dust well.
The IS210AEBIH3BEC belongs to a special assembly group. The number “210” in the series tag confirms this. Most standard boards use “200”. Specifically, this special assembly may include a SCOM grounding output terminal. That terminal can change how the basic assembly works. For instance, similar Mark VIe products reconfigure their grounding through this feature. Consequently, this GE board offers more flexibility in wind turbine cabinets.
This board measures approximately 30 cm by 18 cm. Its height with components is about 3 cm. The gross weight stays at 0.85 kg. Standard operating temperature ranges from -30°C to +65°C. Additionally, storage temperature goes from -40°C to +85°C. Relative humidity tolerance is 5% to 95% non-condensing. This makes the IS210AEBIH3BEC suitable for harsh wind farm locations. Furthermore, the conformal coating prevents corrosion from salt air or humidity.
First, always power down the cabinet before handling this board. Next, locate the dedicated slot for AE bridge interface boards. Insert the board carefully into the backplane connector. Push evenly until the locking tabs engage. Then, secure any front panel screws if present. After that, connect all external cables to their marked terminals. For instance, the SCOM grounding terminal may need a separate ground wire. Finally, power up the system and run a diagnostic check.
Many users ask about the conformal coating. You must not scratch or remove this layer. Also, avoid using chemical cleaners on the IS210AEBIH3BEC. Only use compressed air for dust removal. Meanwhile, keep the board away from direct liquid contact. Therefore, installation inside a sealed cabinet works best.
The IS210AEBIH3BEC provides reliable bridge interface control. GE manufactured it in Salem, Virginia. This domestic production ensures high quality control. Furthermore, the board comes in a new surplus factory package. It has never been installed. Thus, you receive full factory condition. The special assembly design improves grounding options. Conformal coating adds long-term protection. Many wind farms prefer this model because of its stability.
Additionally, this board is easy to identify. Look for the AEBI label on the board. The revision B mark confirms the latest functional updates. Meanwhile, the group three classification matches specific Mark VIe racks. Always verify compatibility before purchase. However, this board works with most standard Mark VIe wind cabinets.
One IS210AEBIH3BEC printed circuit board
One anti-static bag
One foam-lined shipping box
One quick reference card
We ship exclusively via FedEx, UPS, or DHL. Tracking number provided within 24 hours.
1. Is the IS210AEBIH3BEC a new board?
Yes, it is a new surplus factory package. The board has never been used.
2. Can I use this GE board in non-wind applications?
Possibly. However, GE designed it specifically for Mark VIe wind turbines.
3. Does conformal coating require special handling?
Yes. Do not scratch it. Also, avoid solvents or harsh cleaners on the board.
4. What happens if the SCOM terminal is not used?
Then the board operates in default grounding mode. Performance remains normal.
5. How do I confirm compatibility with my system?
Check your Mark VIe rack manual for AEBI board support and group three slots.
| Brand Name | GE |
| Model No. | IS210AEBIH3BEC |
| Product Type | Special PWA |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
