The IC200ALG432 is a versatile analog mixed module from the GE Fanuc VersaMax series. This module combines four input channels and two output channels in a single compact unit. All channels support 4-20 mA current signals with 12-bit resolution. Therefore, this module provides an efficient solution for applications requiring both analog input and output capabilities. It also saves valuable panel space by reducing the number of modules needed. Specifically, the input circuits require an external power supply for the transceiver. Meanwhile, the output circuits need an external power supply to generate the current signal. This design offers flexibility for various industrial automation scenarios.
The IC200ALG432 offers four analog input channels with fast performance. The input update rate reaches just 0.4 milliseconds. Meanwhile, the input response time is 5.0 milliseconds. This combination ensures rapid and accurate signal acquisition. In terms of accuracy, the module achieves +/-0.3% of full scale at 25°C. However, at 60°C, the accuracy is +/-1% maximum. Therefore, temperature affects performance, and proper cooling is recommended. The common mode voltage for this module is 0 Volts. Additionally, the resolution is 12 bits, providing 8 counts for precise measurements.
The output section of the IC200ALG432 features two analog output channels. These channels generate 4-20 mA signals with 12-bit resolution. The output circuits require an external power supply to function properly. This external supply powers the current loop for each output channel. The module includes configurable alarms for different events. Therefore, operators can set appropriate thresholds for their specific applications. The output behavior during faults can also be configured for safe operation.
The IC200ALG432 consumes 160 mA of current for regular operation. This includes the load current for the output channels. The module also draws 60 mA from the 5 VDC backplane bus. For the input circuits, an external power supply is required for the transceiver. Similarly, the output circuits need an external power source. Therefore, proper power planning is essential during system design.
The front panel of the IC200ALG432 includes LED indicators. These indicators show the flow of power and backplane current status. Therefore, operators can quickly verify operational status. The LEDs provide visual confirmation of module health. This simplifies troubleshooting and reduces maintenance time significantly.
This analog mixed module includes comprehensive diagnostic capabilities. The module detects loss of user-side power. It also features configurable alarms for different events. For instance, you can set alarms for high or low limits. This enables proactive maintenance and fault prevention. Consequently, the IC200ALG432 enhances overall system reliability.
The IC200ALG432 should be installed in a controlled environment. Protect the module against electromagnetic noise and airborne pollutants. The ambient temperature should not exceed 60°C. Moreover, no thermal derating occurs in this mixed module. Therefore, it maintains consistent performance across its operating range. Proper installation practices ensure long-term reliability and accuracy.
We package every IC200ALG432 securely for worldwide delivery. Our packaging protects against electrostatic discharge and physical damage. For shipping, we utilize premier global couriers. Therefore, we ship via FedEx, UPS, and DHL to ensure fast and reliable service.
1x GE Fanuc IC200ALG432 Analog Mixed Module
1x Product manual and installation guide
1. How many input and output channels does the IC200ALG432 have?
The IC200ALG432 provides four analog input channels and two analog output channels. All channels support 4-20 mA signals.
2. What is the update rate for this analog module?
The input update rate is 0.4 milliseconds maximum. This ensures fast signal acquisition for time-sensitive applications.
3. Does the IC200ALG432 require external power?
Yes, the input circuits need external power for the transceiver. The output circuits also require an external power supply to generate output signals.
4. What is the accuracy of this module at different temperatures?
At 25°C, accuracy is +/-0.3% of full scale. At 60°C, accuracy is +/-1% maximum. Temperature affects performance significantly.
5. What diagnostic features does this module include?
The IC200ALG432 includes diagnostics for loss of user-side power. It also features configurable alarms for various events and conditions.
