BMXP3420102CL | Schneider Electric Modicon M340 Processor Module
BMXP3420102CL | Schneider Electric Modicon M340 Processor Module
BMXP3420102CL
Manufacturer: N/A Series: N/A Model Number: BMXP3420102CL Weight: N/A Condition: In Stock Availability: 100% Original Brand New Product Origin: U.S.A Shipping port: Xiamen Warranty: 12 Month
Schneider Electric BMXP3420102CL: The Core of Your Modicon M340 System
When your Modicon M340 automation platform needs a reliable processor module, the BMXP3420102CL from Schneider Electric delivers. This genuine processor module is designed for multi-rack configurations, handling up to 1024 discrete I/O and 256 analogue I/O. It requires a memory card (not supplied) to operate, ensuring your application logic and data are stored securely. With integrated CANopen, Ethernet, and serial communication, this module is a versatile choice for complex industrial control tasks.
Key Technical Specifications
Product Type: Processor module for Modicon M340 automation platform.
I/O Capacity: Up to 1024 discrete I/O (multi-rack) and 256 analogue I/O (multi-rack).
Racks/Slots: Supports 4 racks and 11 slots.
Integrated Connections: Non-isolated serial link RJ45 (RS232C/RS485), USB port at 12 Mbit/s, and CANopen master bus SUB-D 9.
Communication Modules: Supports up to 2 Ethernet communication modules and 4 AS-Interface modules.
Memory: Internal RAM 4096 kB (256 kB data, 3584 kB program constants and symbols).
The BMXP3420102CL stands out for its robust communication capabilities. The integrated CANopen master bus supports up to 63 server devices, with transmission rates from 20 kbit/s to 1 Mbit/s. The serial link offers Modbus RTU/ASCII master/slave functionality, and the USB port enables fast programming. For applications requiring Ethernet, the module supports up to two communication modules, making it ideal for networked control systems.
Applications and Use Cases
This processor module excels in manufacturing automation, process control, and infrastructure projects. Its high I/O capacity suits large-scale discrete manufacturing lines, while the CANopen bus is perfect for motion control with independent axes. The Modbus serial links integrate seamlessly with existing SCADA systems. Whether you're building a new M340 system or replacing a faulty processor, the BMXP3420102CL provides the performance and reliability you need.
Comparison with Similar Modules
BMXP3420102CL vs. BMXP342020: The BMXP3420102CL offers 1024 discrete I/O and 256 analogue I/O, while the BMXP342020 supports 2048 discrete I/O. Choose the BMXP3420102CL for standard applications; opt for the higher model for larger systems.
BMXP3420102CL vs. BMXP341000: The BMXP341000 is a lower-cost processor with fewer communication ports. The BMXP3420102CL includes CANopen and Ethernet support, making it more versatile for complex networks.
BMXP3420102CL vs. Third-Party Processors: Genuine Schneider Electric modules ensure seamless compatibility with Modicon M340 racks and software, reducing integration time and risk.
Installation and Maintenance
Install the BMXP3420102CL in a Modicon M340 rack, ensuring the memory card is inserted before power-up. The module operates in ambient temperatures up to 60 °C and requires a clean, dry environment (10…95% relative humidity, non-condensing). Regular inspection of connections and status LEDs helps prevent downtime. The module's diagnostic LEDs indicate processor, I/O, and communication status, simplifying troubleshooting.
Selection Guide
Before purchasing, verify your system's rack configuration and I/O requirements. The BMXP3420102CL supports 4 racks and 11 slots, so ensure your backplane matches. A memory card is mandatory; order it separately if needed. For expert selection support, contact SpareTech Plc. We stock genuine Schneider Electric parts and offer fast worldwide shipping.
FAQs
Q: Does the BMXP3420102CL come with a memory card?
A: No, the memory card is not supplied. You must provide a compatible card for operation.
Q: What communication protocols does this module support?
A: It supports Modbus RTU/ASCII (RS232C/RS485), CANopen master, and Ethernet via communication modules.
Q: Can I use this module in a single-rack configuration?
A: Yes, it supports both single-rack (704 discrete I/O) and multi-rack (1024 discrete I/O) configurations.
Q: What is the power consumption?
A: The module draws 90 mA at 24 V DC from the rack's internal power supply.
Q: Is the BMXP3420102CL suitable for hazardous locations?
A: Yes, it is certified for Class I Division 2 hazardous locations.
Contact SpareTech Plc Today
For pricing and availability of the BMXP3420102CL, contact SpareTech Plc today. Our team provides expert technical support and ensures you get the right part fast. With genuine parts, fast shipping, and immediate dispatch, we keep your operations running smoothly.
Attention: The above product information is sourced from the internet and cannot be guaranteed to be authentic.
For specific product parameters and prices, please contact
SpareTech PLC professionals in a timely manner.
Brand Name
Model No.
BMXP3420102CL
Product Type
Processor module
hasMerchantReturnPolicy
Adjust according to reality
Shippingdetails
Adjust according to reality
Processor module, Modicon M340 automation platform, without memory card, max 1024 discrete
BMXP3420102CL
Main
Range of product
Modicon M340 automation platform
Product or component type
Processor module
Condition of use
Requires a memory card to work (not supplied)
Number of racks
4
Number of slots
11
Discrete I/O processor capacity
1024 I/O multi-rack configuration
704 I/O single-rack configuration
Analogue I/O processor capacity
256 I/O multi-rack configuration
66 I/O single-rack configuration
Number of application specific channel
36
Monitoring
Diagnostic counters Modbus
Event counters Modbus
Complementary
Control channels
Programmable loops
Motion control
Independent axis CANopen
Integrated connection type
Non isolated serial link RJ45 character mode, transmission mode: asynchronous in baseband, RS232C, transmission mode: 2 twisted shielded pairs at 0.3...19.2 kbit/s full duplex
Non isolated serial link RJ45 character mode, transmission mode: asynchronous in baseband, RS485, transmission mode: 1 twisted shielded pair at 0.3...19.2 kbit/s half duplex
Non isolated serial link RJ45, master/slave Modbus, RTU/ASCII, transmission mode: asynchronous in baseband, RS232C, transmission mode: 1 twisted shielded pair at 0.3...19.2 kbit/s half duplex
Non isolated serial link RJ45, master/slave Modbus, RTU/ASCII, transmission mode: asynchronous in baseband, RS485, transmission mode: 1 twisted shielded pair at 0.3...19.2 kbit/s half duplex
USB port at 12 Mbit/s
CANopen master bus SUB-D 9, transmission mode: 2 twisted shielded pairs at 20 kbit/s...1 Mbit/s
Communication module processor capacity
2 Ethernet communication module
4 AS-Interface module
embedded communication service
Network management (NMT) CANopen
Process Data Object (PDO) CANopen
Service Data Object (SDO) CANopen
Special functions (SYNC, EMCY, TIME) CANopen
Transmission rate
1 Mbit/s 0…20 m 0…0.6 m
125 kbit/s 0…500 m 0…10 m
20 kbit/s 0…2500 m 0…300 m
250 kbit/s 0…250 m 0…10 m
50 kbit/s 0…1000 m 0…120 m
500 kbit/s 0…100 m 0…10 m
800 kbit/s 0…40 m 0…6 m
Bus type
CANopen M20 DS 301 V4.02 devices linked by daisy-chaining or tap junctions CSMA/CA
CANopen M20 DS 303-2 devices linked by daisy-chaining or tap junctions CSMA/CA
CANopen M20 DS 405 devices linked by daisy-chaining or tap junctions CSMA/CA
Number of server device(s)
63 CANopen
Number of devices per segment
0…32 (character mode)
0…32 (Modbus)
0…16 for <205 m (CANopen)
0…32 for <185 m (CANopen)
0…64 for <160 m (CANopen)
Number of devices
2 point-to-point character mode
2 point-to-point Modbus
Bus length
0…10 m serial link non isolated character mode segment
0…10 m serial link non isolated Modbus segment
0…1000 m serial link isolated character mode segment
0…1000 m serial link isolated Modbus segment
0…15 m character mode point-to-point
0…15 m Modbus point-to-point
Maximum tap links length
<15 m serial link non isolated character mode segment
<15 m serial link non isolated Modbus segment
<40 m serial link isolated character mode segment
<40 m serial link isolated Modbus segment
Number of addresses
0…248 for character mode
0…248 for Modbus
Requests
1 K data bytes per request character mode
252 data bytes per RTU request Modbus
504 data bytes per ASCII request Modbus
Control parameter
One CRC on each frame (RTU) Modbus
One LRC on each frame (ASCII) character mode
One LRC on each frame (ASCII) Modbus
Memory description
Internal RAM 4096 kB
Internal RAM 256 kB data
Internal RAM 3584 kB program constants and symbols
Maximum size of object areas
256 kB unlocated internal data
32634 %Mi located internal bits
Default size of object areas
1024 %MWi internal words located internal data
256 %KWi constant words located internal data
512 %Mi located internal bits
Application structure
64 event tasks
No auxiliary task
1 cyclic/periodic master task
1 periodic fast task
Execution time per instruction
0.12 µs Boolean
0.17 µs double-length words
0.25 µs single-length words
1.16 µs floating points
Number of instructions per ms
6.4 Kinst/ms 65 % Boolean + 35 % fixed arithmetic
8.1 Kinst/ms 100 % Boolean
System overhead
0.13 ms for fast task
0.7 ms for master task
Current consumption
90 mA at 24 V DC
Supply
Internal power supply via rack
Marking
CE
Status LED
1 LED (green) integrated machine/installation bus operational (CAN RUN)
1 LED (green) processor running (RUN)
1 LED (red) I/O module fault (I/O)
1 LED (red) integrated machine/installation bus fault (CAN ERR)
1 LED (red) memory card fault (CARD ERR)
1 LED (red) processor or system fault (ERR)
1 LED (yellow) activity on Modbus (SER COM)
Product weight
0.21 kg
Environment
Ambient air temperature for operation
0…60 °C
Relative humidity
10…95 % without condensation
IP degree of protection
IP20
Protective treatment
TC
Directives
2014/35/EU - low voltage directive
2014/30/EU - electromagnetic compatibility
Product certifications
CE
UL
CSA
RCM
EAC
Merchant Navy
Standards
EN 61131-2
EN/IEC 61010-2-201
UL 61010-2-201
CSA C22.2 No 61010-2-201
IACS E10
EN/IEC 61000-6-5, interface type 1 and type 2
EN/IEC 61850-3, location G
Environmental characteristic
Hazardous location class I division 2
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
5.5 cm
Package 1 Width
11.0 cm
Package 1 Length
12.0 cm
Package 1 Weight
252.0 g
Unit Type of Package 2
S02
Number of Units in Package 2
15
Package 2 Height
15.0 cm
Package 2 Width
30.0 cm
Package 2 Length
40.0 cm
Package 2 Weight
4.581 kg SpareTech PLC provides you with a PDF version of the instructions about
N/A BMXP3420102CL,
where you can download the
N/A BMXP3420102CL manual PDF for free： Download PDF
