BMEP582040H | Schneider Electric Modicon M580 Processor Module

Name: BMEP582040H | Schneider Electric Modicon M580 Processor Module
Brand: N/A
Availability: InStock
Rating: 4.6 (16 reviews)

BMEP582040H

Manufacturer: N/A
Series: N/A
Model Number: BMEP582040H
Weight: N/A
Condition: In Stock
Availability: 100% Original Brand New
Product Origin: U.S.A
Shipping port: Xiamen
Warranty: 12 Month

What Happens When a Critical Process Controller Fails in a Harsh Plant Environment?

Downtime compounds fast. Dust, gas, vibration, and extreme temperatures destroy standard controllers. The Schneider Electric BMEP582040H is a Modicon M580 processor module engineered specifically for severe environments—built to keep your process running when conditions turn brutal.

Product Overview

This processor module belongs to Schneider Electric's Modicon M580 range. It handles 4 racks, supports 2048 discrete I/O and 512 analog I/O locally, and manages 8 remote I/O stations across 2 remote drops plus 64 distributed equipment nodes. With conformal coating and broad hazardous-area approvals, it suits oil and gas, water treatment, and heavy manufacturing where ordinary PLCs fail early.

Key Technical Specifications

Local I/O capacity: 2048 discrete, 512 analog
Racks: 4; application-specific channels (local rack): 72
Integrated connections: 1 Ethernet TCP/IP service port, 2 Ethernet TCP/IP device network, USB mini B
Communication module capacity: 2 Ethernet modules, 16 AS-Interface modules
Memory: 4 GB expandable flash, 8 MB program RAM, 768 kB data RAM, 10 kB system RAM
Processing speed: 30 Kinst/ms (65% Boolean + 35% fixed arithmetic); 40 Kinst/ms (100% Boolean)
Current consumption: 270 mA at 24 V DC
Operating temperature: -25…70 °C; storage: -40…85 °C
Relative humidity: 5…95% at 55 °C without condensation
Protection: IP20; vibration resistance 3 gn; shock resistance 30 gn
MTBF: 775,000 hours
Net weight: 0.849 kg

Built for Severe Environments

Conformal coating plus gas-resistant class Gx (ISA S71.04) and 3C4 (IEC 60721-3-3) ratings protect internal circuitry from corrosive atmospheres. Dust, sand, salt, mold, and fungal spore resistance meet IEC 60721-3-3 and IEC 68252 standards. Certifications include CE, UL, CSA, RCM, EAC, Merchant Navy, ATEX Zone 2/22, and IECEx Zone 2/22—so the BMEP582040H fits hazardous locations without extra enclosures.

Applications That Demand This Module

Oil and gas processing—ATEX and IECEx Zone 2/22 approvals let you deploy directly in classified areas. Water and wastewater treatment—2048 discrete points handle pump, valve, and alarm I/O across a full plant. Heavy manufacturing—30 Kinst/ms Boolean execution keeps high-speed lines responsive while conformal coating resists coolant mist and dust.

Installation and Setup Notes

The module draws power internally via the rack—no separate supply wiring needed beyond the 270 mA at 24 V DC budget. Mount in a rack compatible with the Modicon M580 platform. Seven status LEDs (RUN, ERR, I/O, DL, BACKUP, ETH MS, Eth NS) give immediate visual diagnostics. For fieldbus integration, wiring into Ethernet networks may require an external gateway or connection module; confirm cables and gateways with your supplier.

Maintenance and Reliability

At 775,000 hours MTBF, this module is built for long service. Inspect periodically for dust buildup on the front panel and verify LED status during routine rounds. Follow Schneider Electric's safety manual for all maintenance. The conformal coating resists common contaminants, reducing cleaning frequency and extending service life.

Selection Checklist

Before ordering, verify rack compatibility, confirm your I/O count fits the 2048 discrete / 512 analog envelope, and check that your environment matches the IP20 and temperature ratings. The BMEP582040H ships from France (GTIN 3595864174495). Please verify current lifecycle status and availability with SpareTech Plc before ordering.

Contact SpareTech Plc today for pricing and availability.

Figure 1: Front view of the Schneider Electric BMEP582040H Processor module showing its physical design and enclosure.
Figure 2: Technical layout and connection details for the Schneider Electric BMEP582040H Processor module.

Attention: The above product information is sourced from the internet and cannot be guaranteed to be authentic. For specific product parameters and prices, please contact SpareTech PLC professionals in a timely manner.

Brand Name
Model No.	BMEP582040H
Product Type	Processor module
hasMerchantReturnPolicy	Adjust according to reality
Shippingdetails	Adjust according to reality

BMEP582040H Main Range of Product Modicon M580 Product or Component Type Processor module Product Specific Application For severe environments Complementary Number of racks 4 Local I/O processor capacity (discrete) 2048 I/O Local I/O processor capacity (analog) 512 I/O Number of application specific channel (local rack) 72 Application specific I/O Counter HART SSI encoder Accurate time stamping Motion control Serial link Checks Process control Control channels Programmable loops Integrated connection type 1 Ethernet TCP/IP service port 2 Ethernet TCP/IP device network USB type mini B Number of remote I/O station 8 - 2 remote drop Number of distributed equipment 64 Communication module processor capacity 2 Ethernet communication module 16 AS-Interface module Communication Service RIO scanner DIO scanner Memory description Expandable flash, 4 GB data storage Integrated RAM, 10 kB system memory Integrated RAM, 8 MB program Integrated RAM, 768 kB data Application structure 1 periodic fast task 64 event tasks 1 cyclic/periodic master task 2 auxiliary tasks Number of instructions per ms 30 Kinst/ms 65 % Boolean + 35 % fixed arithmetic 40 Kinst/ms 100 % Boolean Current consumption 270 mA 24 V DC MTBF reliability 775000 H Marking CE Environment Vibration resistance 3 gn Shock resistance 30 gn Ambient air temperature for operation -13…158 °F (-25…70 °C) Ambient Air Temperature for Storage -40…185 °F (-40…85 °C) Operating altitude 0...6561.68 ft (0...2000 m) 2000...5000 m with derating factor Relative humidity 5…95 % 131 °F (55 °C) without condensation IP Degree of Protection IP20 Directives 2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility 2014/34/EU - ATEX directive Product certifications CE UL CSA RCM EAC Merchant Navy ATEX zone 2/22 IECEx zone 2/22 Standards IEC 61131-2 IEC 61010-2-201 UL 61010-2-201 CSA C22.2 No 61010-2-201 IACS E10 EN/IEC 61000-6-5, interface type 1 and type 2 EN/IEC 61850-3, location G IEC 60079-0 Environmental characteristic Gas resistant class Gx ISA S71.04 Gas resistant class 3C4 IEC 60721-3-3 Dust resistant class 3S4 IEC 60721-3-3 Sand resistant class 3S4 IEC 60721-3-3 Salt resistant level 2 IEC 68252 Mold growth resistant class 3B2 IEC 60721-3-3 Fungal spore resistant class 3B2 IEC 60721-3-3 Hazardous location class I division 2 Protective treatment Conformal coating Supply Internal power supply via rack Status LED 1 LED (Green) processor running (RUN) 1 LED (Red) processor or system fault (ERR) 1 LED (Red) I/O module fault (I/O) 1 LED (Green) download in progress (DL) 1 LED (Red) memory card or CPU flash fault (BACKUP) 1 LED (green/red) ETH MS (Ethernet port configuration status) 1 LED (green/red) Eth NS (Ethernet network status) Net Weight 1.872 lb(US) (0.849 kg) Ordering and shipping details Category US1PC3418161 Discount Schedule PC34 GTIN 3595864174495 Returnability No Country of origin FR Packing Units Unit Type of Package 1 PCE Nbr. of units in pkg. 1 Package 1 Height 3.54 in (9.000 cm) Package 1 Width 7.09 in (18.000 cm) Package 1 Length 10.04 in (25.500 cm) Package weight(Lbs) 31.076 oz (881.000 g) Unit Type of Package 2 S03 Number of Units in Package 2 6 Package 2 Height 11.81 in (30.000 cm) Package 2 Width 11.81 in (30.000 cm) Package 2 Length 15.75 in (40.000 cm) Package 2 Weight 12.566 lb(US) (5.700 kg)
SpareTech PLC provides you with a PDF version of the instructions about N/A BMEP582040H, where you can download the N/A BMEP582040H manual PDF for free：
Download PDF
