110XTS00122 Modicon Momentum I/O Base Module Schneider

Schneider 110XTS00122 Modicon Momentum I/O Base Module

Product Introduction

The 110XTS00122 from Schneider Electric anchors the Modicon Momentum automation platform. This I/O base module connects Momentum processors and I/O modules. It creates a unified control solution for distributed architectures. Moreover, it offers dual-protocol communication, supporting both Modbus Plus and Ethernet networks. Consequently, you gain significant flexibility when integrating into new or existing systems. The Schneider 110XTS00122 also simplifies installation with its versatile mounting options.

Technical Specifications

The 110XTS00122 I/O base module operates with a voltage of 5 VDC, which it receives directly from the connected processor module. This design centralizes power distribution and minimizes wiring complexity. Furthermore, it features a single base slot that accommodates either a Momentum processor or a compatible I/O module. Specifically, the module communicates over two primary bus types: Modbus Plus and Ethernet. This dual-protocol support allows for seamless network integration, letting you choose the best communication method for your application. Additionally, the module is built with a low power consumption profile, making it a good fit for applications where energy efficiency is a priority.

Mechanical and Environmental Parameters

The robust construction of the 110XTS00122 ensures reliable operation in demanding industrial settings. Its enclosure features a protection class of IP20, which guards against solid objects larger than 12mm. The module is made from high-impact plastic, providing excellent resistance to physical damage and vibration. In addition, it operates within a wide temperature range, functioning in ambient conditions from 0 °C to 60 °C. Meanwhile, its storage capabilities are even broader, withstanding temperatures from -40 °C to 85 °C. The module also maintains stable performance in environments with humidity levels between 5% and 95% (non-condensing).

Installation Guide

Installing this base module is straightforward, thanks to its flexible mounting design. You can mount the unit on a standard DIN rail or directly onto a panel. For DIN rail mounting, simply snap the module onto the rail until it clicks securely into place. For panel mounting, use the integrated mounting holes and appropriate screws. Once mounted, you can insert a compatible Momentum processor or I/O module into the single base slot. After that, connect the appropriate communication cable for either Modbus Plus or Ethernet. Finally, the power is supplied automatically from the processor module, so no separate power wiring is needed for the base itself.

Why Choose the 110XTS00122 for Your System

This base module stands out because it offers true protocol flexibility. Specifically, the 110XTS00122 supports both Modbus Plus and Ethernet without requiring any hardware changes. Therefore, you can deploy it in legacy Modbus Plus networks or modern Ethernet-based architectures with equal ease. Additionally, its compact single-slot design saves valuable panel space while still accommodating a full Momentum processor or I/O module. For system integrators, this means fewer spare parts to stock and simpler upgrade paths. Furthermore, the low power draw reduces the load on the processor's power supply, improving overall system reliability and longevity.

Application Scenarios

The Schneider 110XTS00122 is ideally suited for distributed control systems where remote I/O racks are needed. For instance, it works well in material handling systems, packaging machinery, and small process skids. Similarly, it is a popular choice for retrofitting older Modbus Plus networks with newer Ethernet-enabled supervisory systems. Moreover, the module's wide operating temperature range makes it suitable for both climate-controlled control rooms and more challenging floor-level installations. Its IP20 protection also ensures safe operation inside standard electrical enclosures.

Packaging List

When you receive your order, the package will contain the following items:

• Schneider Electric 110XTS00122 I/O Base Module

• Standard mounting hardware for panel installation

• Product documentation and quick-start guide

Shipping Information

We ship all orders via leading carriers including FedEx, UPS, and DHL. These services provide reliable tracking and fast global delivery. We carefully package every module to prevent damage during transit. Once shipped, you will receive a tracking number via email. Expedited shipping options are also available upon request.

Frequently Asked Questions (FAQ)

Q1: Can the 110XTS00122 support both Modbus Plus and Ethernet simultaneously?
A1: No, the module uses one communication protocol at a time. However, you can easily select either Modbus Plus or Ethernet based on your network requirements without any hardware modification.

Q2: Does the 110XTS00122 require a separate power supply?
A2: No, it does not. The 110XTS00122 receives its operating power directly from the connected Momentum processor module at 5 VDC. This simplifies wiring and reduces overall component count.

Q3: What types of modules can I install in the 110XTS00122?
A3: This base module accepts either a Momentum processor or a compatible Momentum I/O module. It provides one single base slot for these devices.

Q4: Is the 110XTS00122 suitable for outdoor installations?
A4: Not directly. While it has a wide storage temperature range, its operating range is 0 °C to 60 °C and it is rated IP20. You should install it inside a suitable protective enclosure for outdoor use.

Q5: What mounting options are available for the 110XTS00122?
A5: You can mount the 110XTS00122 on a standard DIN rail or directly onto a panel using the integrated mounting holes. Both methods are quick and require only basic tools.
