IC695CBL001 RX3i Controller Cable: Installation & Maintenance Guide
Product Introduction
The IC695CBL001 is a purpose-built serial cable for the GE Fanuc RX3i controller series. This cable enables reliable RS-232 communication between the CPU and external devices. Specifically, the IC695CBL001 features a 15-pin D-sub connector on the controller side. Moreover, this assembly provides a standard 9-pin D-sub connector for the device side. The IC695CBL001 supports baud rates up to 115.2 Kbps. This cable simplifies the programming and monitoring process for your automation system. Furthermore, the IC695CBL001 ensures a secure connection during data transfer.
Core Value
The IC695CBL001 offers exceptional durability and signal integrity for demanding plant environments. Firstly, this cable minimizes data loss during program uploads and downloads. Secondly, the IC695CBL001 reduces troubleshooting time with its reliable construction. This cable directly supports system uptime by providing stable communications. Additionally, the IC695CBL001 simplifies initial system start-up. Using this cable ensures you maintain consistent connectivity. Therefore, the IC695CBL001 is essential for efficient RX3i operations.
Technical Insights
The IC695CBL001 uses shielded twisted-pair wiring to reduce electromagnetic interference. Specifically, the cable pinout connects the TX, RX, and ground signals correctly. This cable spans 2.5 meters, offering flexible placement for your workstation. Moreover, the IC695CBL001 integrates seamlessly with Proficy Machine Edition software. The cable supports standard RS-232 voltage levels. Therefore, the IC695CBL001 works with most programming laptops. Additionally, this assembly includes ferrite beads for noise suppression. Such features ensure the IC695CBL001 delivers error-free communication.
Installation & Maintenance
Installing the IC695CBL001 requires a simple plug-and-play process. Connect the 15-pin end firmly to the RX3i CPU port. Then, attach the 9-pin connector to your programming device. Ensure you secure both locking screws to prevent accidental disconnection. For maintenance, inspect the IC695CBL001 regularly for physical damage. Specifically, check the connectors for bent pins or corrosion. Keep the cable away from high-voltage AC power lines. Also, avoid bending the IC695CBL001 sharply. Replace the IC695CBL001 immediately if you find any wear. Proper care extends the life of the IC695CBL001 significantly.
Buyer’s Guide FAQ
Q1: What is the primary use of the IC695CBL001?
A1: The IC695CBL001 connects a GE Fanuc RX3i CPU to a programming terminal for software uploads and troubleshooting.
Q2: What devices can connect to the IC695CBL001?
A2: The IC695CBL001 connects to any standard DTE device, including PCs, laptops, and HMIs with a 9-pin serial port.
Q3: How long is the IC695CBL001 cable assembly?
A3: The IC695CBL001 measures approximately 2.5 meters in length, which provides adequate reach in most control cabinets.
Q4: Does the IC695CBL001 require a specific driver?
A4: No, the IC695CBL001 uses standard serial protocols and does not require proprietary drivers for operation.
Q5: Can I use the IC695CBL001 with the RX7i controller?
A5: The IC695CBL001 is specifically designed for the RX3i series. Check the manual before using it with other controllers.
