The Evolution of Vibration Monitoring in Industrial Automation
In the rapidly advancing field of industrial automation, the ability to monitor equipment health in real time has become a cornerstone of operational efficiency. As factories embrace Industry 4.0, the demand for precise, reliable vibration sensors has surged. These sensors help prevent unplanned downtime by detecting early signs of mechanical wear. The Bently Nevada 200355-09-00-00 accelerometer represents a key component in this evolution, offering robust performance for critical asset protection.
Introducing the 200355-09-00-00 Accelerometer
SpareTechPLC now offers the Bently Nevada 200355-09-00-00, a high-performance accelerometer from the 200350&200355 series. This sensor is designed for permanent installation in demanding industrial environments. It provides accurate vibration data to support predictive maintenance strategies. Manufactured in the U.S.A., this model combines proven technology with rugged construction.
Technical Specifications and Performance
The 200355-09-00-00 delivers a sensitivity of 100 mV/g ±20% (10.2 mV/m/s² ±20%), ensuring precise measurement across a frequency range of 30-600,000 cpm (0.5-10,000 Hz). It can measure up to ±50 g, making it suitable for a wide variety of rotating machinery. The sensor features a mounted resonant frequency of 1500 kcpm (25 kHz) and amplitude linearity of ±1%, guaranteeing accurate readings even under dynamic conditions. Its output bias voltage is 8 to 12 VDC, with an excitation voltage requirement of 18 to 28 VDC and constant current excitation of 2 to 20 mA. The discharge time constant is ≥0.3 sec, and output impedance is less than 150 ohms. Electrical isolation from the case exceeds 108 ohms, ensuring signal integrity.
Durable Design for Harsh Environments
Built to withstand extreme conditions, the 200355-09-00-00 operates in temperatures from -65°F to +250 ºF (-54°C to +121 ºC). It can survive shock up to 5,000 g pk and functions in 100% relative humidity, condensing and non-submerged. The enclosure rating is IP68, providing protection against dust and prolonged immersion. The housing is made of stainless steel with welded hermetic sealing, and the sensing element is ceramic with a shear geometry. The electrical connector is a 2-Pin Mil-C-5015 located at the top. The mounting thread is 1/4-28 female, with a recommended mounting torque of 2 to 5 ft-lb (2.7 to 6.8 N-m). The hex size is 11/16” (1.8 cm), height is 1.65” (4.24 cm), and weight is 0.051 kg.
Real-World Application Example
In a typical petrochemical plant, pumps and compressors operate continuously under high stress. The 200355-09-00-00 can be mounted directly on bearing housings to monitor vibration levels. Its wide frequency range and high shock survivability make it ideal for such critical rotating equipment. By providing early warning of bearing degradation, this accelerometer helps maintenance teams schedule repairs before catastrophic failure occurs.
Frequently Asked Questions About the 200355-09-00-00
What is the sensitivity of the 200355-09-00-00 accelerometer?
The sensitivity is 100 mV/g ±20% (10.2 mV/m/s² ±20%), as specified in the product data.
What is the operating temperature range for this accelerometer?
The operating temperature range is -65°F to +250 ºF (-54°C to +121 ºC).
What is the enclosure rating of the 200355-09-00-00?
The enclosure rating is IP68, meaning it is protected against dust and prolonged immersion in water.
What type of electrical connector does this accelerometer use?
It uses a 2-Pin Mil-C-5015 electrical connector located at the top of the sensor.
What is the mounting thread size for the 200355-09-00-00?
The mounting thread is 1/4-28 female, with a recommended mounting torque of 2 to 5 ft-lb (2.7 to 6.8 N-m).
