330130-040-02-00 3300 XL Cable Technical Guide
Product Introduction
The Bently Nevada 330130-040-02-00 belongs to the 3300 XL extension cable family. This model offers a 4.0-meter length with a standard connector protector. The cable uses 75 Ω triaxial FEP insulation to maintain signal integrity. Moreover, this cable supports the 3300 XL 8 mm proximity transducer system. It connects the probe lead to the Proximitor sensor's input connector. Therefore, the 330130-040-02-00 plays a vital role in the measurement loop. The cable transmits static and dynamic displacement signals. It also handles Keyphasor reference signals for automated monitoring.
Core Value
The primary value of the 330130-040-02-00 lies in its precision. It maintains signal variation below 2 mV per volt input change. This feature guarantees measurement accuracy. Additionally, the cable offers a frequency response from 0 to 10 kHz. This range covers typical vibration monitoring needs. The cable's construction enhances system reliability. Its armored design secures probe connections effectively. Therefore, the 330130-040-02-00 minimizes downtime. It supports predictive maintenance strategies.
Technical Insights
Understanding the cable's specifications helps in system design. The Bently Nevada 330130-040-02-00 features an output resistance of 50 Ω. Its typical capacitance is 69.9 pF/m. These parameters are critical for system compatibility. Meanwhile, the cable operates effectively from -52°C to +177°C. This wide temperature range supports extreme environments. The cable's suffix code provides essential details. The "-040" indicates a 4.0-meter length. The "-02" specifies the standard connector protector.
Installation & Maintenance
Proper installation ensures optimal performance for the 330130-040-02-00. Firstly, inspect the cable for any damage before installation. Secondly, connect the cable securely to the probe and the Proximitor sensor. Ensure the connector is fully engaged to avoid signal loss. Moreover, avoid sharp bends during routing. This practice prevents internal wire damage. For maintenance, regularly check the cable for abrasion or corrosion. Clean the connectors with an approved solvent periodically. Furthermore, verify the cable's continuity and insulation resistance during routine checks.
Buyer’s Guide FAQ
Q1: What is the length of the 330130-040-02-00 cable?
A1: The 330130-040-02-00 cable has a length of 4.0 meters.
Q2: Which system uses this extension cable?
A2: This cable is a component of the 3300 XL 8 mm Proximity Transducer System.
Q3: What is the operating temperature range?
A3: This cable operates effectively from -52°C to +177°C.
Q4: How does the cable ensure signal integrity?
A4: The cable uses 75 Ω triaxial FEP insulation and maintains signal variation below 2 mV/V.
Q5: What does the "-02" suffix designate?
A5: The "-02" suffix specifies the standard connector protector for the cable.
