330130-045-13-05 3300 XL 8mm Proximity Probe Installation Guide
Product Introduction
The 330130-045-13-05 belongs to the Bently Nevada 3300 XL series. This 8mm probe is a non-contacting eddy current sensor. It measures radial vibration and axial position. The system consists of the probe, extension cable, and driver. This design supports continuous machine health monitoring. You will find it in turbines, compressors, and pumps. This model ensures high accuracy and stability.
Core Value
This sensor offers linear output over a wide range. Firstly, it provides accurate gap voltage readings. Moreover, it withstands harsh industrial environments. In addition, the 330130-045-13-05 reduces installation time. It uses a standard probe tip diameter. Therefore, it directly replaces older models. Specifically, it enhances predictive maintenance strategies. Besides, it is fully compatible with Bently Nevada monitors.
Technical Insights
The 330130-045-13-05 operates on the eddy current principle. It requires a specific target material. The system includes a 5-meter probe length. Its cable is armored for durability. Furthermore, the driver supports a wide temperature range. You must set the initial gap correctly. The standard scale factor is 7.87 V/mm. This ensures precise displacement measurement. Meanwhile, the linear range is 2 mm. This range suits most critical machinery.
Installation & Maintenance
Proper installation is crucial for the 330130-045-13-05. Firstly, clean the mounting hole thoroughly. Then, inspect the probe tip for damage. Use the correct torque for mounting. After that, connect the extension cable securely. Specifically, avoid bending the cable sharply. The gap must be set using a calibrated micrometer. You should use a Bently Nevada proximitor for setup. Furthermore, regularly check the cable integrity. Test the loop impedance periodically. Document all resistance readings. This process ensures signal accuracy. Always follow the API 670 standards.
Buyer’s Guide FAQ
Q: What is the length of the 330130-045-13-05?
A: The 330130-045-13-05 has a total length of 5 meters (16.4 feet).
Q: What is the tip material?
A: The probe tip uses PPS and ceramic materials. This resists chemical attacks.
Q: Can I use this with other brands?
A: We recommend using Bently Nevada drivers for best performance.
Q: How do I check if the probe is bad?
A: Measure the DC voltage. Look for open circuits or shorts.
Q: What is the temperature rating?
A: The standard probe operates from -35°C to +177°C.
