Why do industrial vibration monitoring systems often fail to deliver reliable data in extreme conditions? The answer often lies in the sensor's ability to withstand harsh environments while maintaining accuracy. The Bently Nevada 200350-11-00-CN accelerometer, available at SpareTechPLC, addresses this challenge with a robust design and precise specifications.
Industry Trends in Vibration Monitoring
The demand for high-performance accelerometers is growing as industries adopt predictive maintenance strategies. Facilities require sensors that operate reliably across wide temperature ranges and in wet, condensing conditions. The 200350-11-00-CN meets these needs with an operating temperature range of -65°F to +250 °F (-54°C to +121 °C) and 100% relative humidity tolerance, non-submerged.
Introducing the 200350-11-00-CN
Part of the 200350&200355 series, the 200350-11-00-CN is a 200350 Accelerometer manufactured by Bently Nevada in the U.S.A. It features a sensitivity of 100 mV/g ±20% (10.2 mV/m/s² ±20%) and a frequency range of 30-600,000 cpm (0.5-10,000 Hz). The measurement range is ±50g, making it suitable for a variety of rotating machinery applications.
Technical Specifications and Performance
The accelerometer offers a mounted resonant frequency of 1500 kcpm (25 kHz) and amplitude linearity of ±1%. Its broadband electrical noise (1-10 kHz) is 350 μg (3,434 μm/s²), ensuring clean signals. The output bias voltage ranges from 8 to 12 VDC, with an excitation voltage of 18 to 28 VDC and constant current excitation of 2 to 20 mA. The settling time within 1% of bias is 2.0 seconds, and the output impedance is less than 150 ohms. The discharge time constant is ≥0.3 seconds, and electrical isolation from the case exceeds 108 ohms.
Applications in Modern Manufacturing
In a typical packaging line application, the 200350-11-00-CN helps maintain uptime by detecting early signs of bearing wear or imbalance. Its IP68 enclosure rating allows it to operate in dusty and wet environments without performance degradation. The welded hermetic sealing and stainless steel housing provide durability against corrosion and physical shock, with shock survivability of 5,000 g pk.
Real-World Application Example
Consider a chemical processing plant where pumps run continuously in a humid, condensing atmosphere. The 200350-11-00-CN, with its 100% relative humidity tolerance and IP68 rating, delivers reliable vibration data. Its M6x1 adhesive stud mount (mounting stud option 11) simplifies installation on existing machinery.
Why Choose SpareTechPLC
SpareTechPLC offers genuine Bently Nevada 200350-11-00-CN accelerometers with assured quality and fast shipping. Our team understands industrial automation spare parts and can help you select the right sensor for your application. Contact us for competitive pricing and availability.
Frequently Asked Questions About the 200350-11-00-CN
What is the sensitivity of the 200350-11-00-CN accelerometer?
The sensitivity is 100 mV/g ±20% (10.2 mV/m/s² ±20%). This tolerance ensures consistent performance across units.
What is the enclosure rating of this accelerometer?
The enclosure rating is IP68, meaning it is protected against dust ingress and continuous immersion in water under specified conditions.
What mounting options are available for the 200350-11-00-CN?
The mounting stud option is 11, which is an M6x1 adhesive stud mount. The mounting thread is 1/4-28 Female, and the recommended mounting torque is 2 to 5 ft-lb (2.7 to 6.8 N-m).
What is the operating temperature range for this accelerometer?
The operating temperature range is -65°F to +250 °F (-54°C to +121 °C), allowing use in extreme industrial environments.
