Product Introduction
The Siemens 6FX5002-2DC10-1BF0 features a 4-core power design. Specifically, it includes three phases plus a ground conductor. The cable length measures 10 meters. Moreover, it uses a straight connector on the motor side. The drive side terminates with a D-sub or open end. Many field engineers choose this cable for retrofit jobs. Furthermore, the jacket material resists oil and coolant. Therefore, the Siemens 6FX5002-2DC10-1BF0 suits machine tool environments.
Core Value
This cable simplifies drive-to-motor wiring. Firstly, it eliminates field crimping errors. Secondly, the pre-assembled connectors save installation time. In addition, the cable supports continuous flexing applications. The Siemens 6FX5002-2DC10-1BF0 also reduces EMI emissions. Specifically, the shielded design blocks electrical noise. Besides, the conductor cross-section suits 10A to 20A drives. Meanwhile, the operating voltage reaches 600V AC.
Technical Insights
The Siemens 6FX5002-2DC10-1BF0 uses flexible copper strands. Each conductor has a cross-section of 1.5 mm². Furthermore, the overall shield coverage exceeds 85%. The bending radius for fixed installation is 5x the cable diameter. For moving applications, use 10x the diameter. The temperature range spans -20°C to +80°C. Moreover, the connector housing meets IP67 protection. Therefore, this cable works in wet or dusty areas. Specifically, the Siemens 6FX5002-2DC10-1BF0 complies with CE and UL standards for industrial use.
Installation & Maintenance
Start by disconnecting all power. Firstly, route the cable away from signal lines. Maintain a 20 cm separation gap. Secondly, secure the cable with plastic clamps. Do not over-tighten. Then, connect the motor side first. Torque the connector nut to 1.5 Nm. For the drive side, match the phase order U, V, W. Meanwhile, verify ground continuity with a multimeter. For maintenance, inspect the jacket monthly. Look for cuts or abrasion. Furthermore, replace the Siemens 6FX5002-2DC10-1BF0 if you find shield damage. Also, clean the connector pins annually.
Buyer’s Guide FAQ
Q1: Which drives work with the Siemens 6FX5002-2DC10-1BF0?
A1: This cable fits SINAMICS S120, G120, and V90 drives. It also connects to SIMOTICS S-1FL6 motors.
Q2: Can I cut this cable to a shorter length?
A2: Yes, but you must re-terminate the drive side. Use Siemens-recommended crimp contacts.
Q3: What is the maximum current for this cable?
A3: The Siemens 6FX5002-2DC10-1BF0 handles 16A continuously. For peak loads, it tolerates 20A for short periods.
Q4: How do I test cable shielding integrity?
A4: Use a megohmmeter between shield and ground. The resistance should exceed 100 MΩ.
Q5: Does the Siemens 6FX5002-2DC10-1BF0 support chain flexing?
A5: Yes, it supports flexing applications. However, limit the travel speed to 3 m/s. Also, maintain the minimum bending radius.
