The F3YD04-7N from Yokogawa Electric is a high-performance transistor output module designed for industrial automation systems. Specifically, this module provides four independent output points, each capable of handling 24V DC loads up to 2A. The unit uses photocoupler isolation to protect the control side from electrical noise and voltage spikes. Meanwhile, its compact design and 10-point terminal block make wiring straightforward and secure.
Furthermore, the F3YD04-7N supports a wide range of applications, from relay replacement to direct solenoid and lamp driving. The module features a maximum ON voltage of just 0.5V DC and an off-time leakage current of only 0.1mA. As a result, it minimizes power loss and ensures clean signal switching. Additionally, a built-in zener diode provides surge protection, extending the module's service life in harsh industrial environments.
The F3YD04-7N also includes a CPU error output function with HOLD/RESET behavior. For sequence CPUs, the initial value is RESET, while BASIC CPUs always set to HOLD. When using an OS-free CPU, the initial value is HOLD, and users can specify the setting for each group of 8 points. Besides, all module outputs can be set collectively, offering flexible system configuration.
The F3YD04-7N delivers robust performance with clearly defined electrical characteristics. First, the rated load voltage is 24V DC, and the maximum load current reaches 2A per point. The response time from OFF to ON is 5ms maximum, while ON to OFF is 3ms maximum. These fast switching times support precise control in time-sensitive operations.
Moreover, the module's ON voltage is 0.5V DC maximum, and the off-time leakage current is 0.1mA maximum. The output type is transistor contact with all points independent. For isolation, the unit uses photocoupler technology, ensuring safe separation between input and output circuits. In addition, current consumption is only 85mA at 5V DC, and no external power supply is required. This efficiency reduces wiring complexity and saves panel space.
The F3YD04-7N weighs approximately 140g and uses a 10-point terminal block with M3.5 screws for external connections. The operating temperature range is 0 to 55°C, while the storage temperature range is -20°C to 75°C. Besides, the operating and storage humidity range is 10 to 90% RH, non-condensing. The surrounding atmosphere must be free of corrosive gases, flammable gases, or heavy dust. These specifications ensure reliable performance in typical industrial environments.
Installing the F3YD04-7N requires careful attention to wiring and environmental conditions. First, mount the module in a location that meets the specified temperature and humidity ranges. Next, connect the 24V DC load and power supply using the 10-point terminal block with M3.5 screws. Ensure all connections are tight to prevent intermittent faults. Additionally, verify that the surrounding atmosphere is free of corrosive or flammable gases. Finally, confirm that the CPU error output setting matches your CPU type before powering up the system.
1 x Yokogawa F3YD04-7N Transistor Output Module
1 x Terminal Block Cover
1 x Installation Guide
Q1: What is the maximum load current per point for the F3YD04-7N?
A1: The F3YD04-7N supports a maximum load current of 2A per point, with all four points independent.
Q2: Does this module require an external power supply?
A2: No, the F3YD04-7N does not require an external power supply. It consumes 85mA at 5V DC from the backplane.
Q3: What is the response time of this transistor output module?
A3: The OFF to ON response time is 5ms maximum, and the ON to OFF response time is 3ms maximum.
Q4: How does the CPU error output behave with different CPU types?
A4: For sequence CPUs, the initial value is RESET. For BASIC CPUs, it is always set to HOLD. For OS-free CPUs, the initial value is HOLD, and users can specify settings for each group of 8 points.
Q5: What shipping methods are available for this product?
A5: We ship via Fedex, UPS, and DHL to ensure fast and reliable delivery worldwide.
| Brand Name | |
| Model No. | F3YD04-7N |
| Product Type | Output Module |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
