The KV-N24DT is a terminal-block type programmable controller in the Keyence KV Nano series. Specifically, the "D" suffix identifies a 24 VDC supply voltage, which suits battery-backed systems, mobile equipment, and panels without AC mains. In addition, the unit packs 14 input points and 10 output points into a single compact chassis. Therefore, machine builders can reduce panel size and wiring effort on small automation projects. The KV-N24DT also accepts up to 8 expansion units through its backplane, so users can grow the system to 256 I/O points when production needs change.
This controller runs on a nominal supply voltage of 24 VDC with a tolerance of +/-10%. As a result, it integrates easily into DC-powered control cabinets and vehicle-mounted equipment. Besides, it delivers a 24 VDC output power supply rated at 0.6 A for powering sensors and small loads. The output circuits use MOSFET transistors in sink (NPN) configuration, rated at 30 VDC and 0.5 A per point. Consequently, these solid-state outputs switch faster and last longer than mechanical relays in high-frequency applications.
Program capacity is 8k steps, with a basic instruction speed of 50 ns minimum and an application instruction speed of 170 ns minimum. Moreover, this throughput keeps scan times short even when the program includes data handling and comparison logic. Users program the KV-N24DT with Expanded Ladder, KV Script, or mnemonic instructions through Keyence KV STUDIO software.
For motion tasks, the KV-N24DT supplies 2 axes of positioning pulse output at up to 100 kHz. Meanwhile, the high-speed counter block supports 2 points of 32-bit auto-reset counting at 100 kHz single-phase or 50 kHz phase-difference input. These functions cover encoder feedback, speed measurement, and simple stepper or servo indexing.
A built-in RS-232C modular port handles KV STUDIO programming and no-protocol serial links to barcode readers or other devices. Furthermore, optional communication modules can be mounted on the backplane when the application needs additional serial channels or network connectivity.
The KV-N24DT operates from 0 to +55°C without freezing and tolerates 5 to 95% RH without condensation. Storage temperature ranges from -25 to +75°C. The unit resists vibration at 5–9 Hz with 3.5 mm amplitude and 9–150 Hz at 9.8 m/s² intermittently, plus shock of 150 m/s² for 11 ms in three axes. In addition, noise immunity meets IEC standards at 1500 Vp-p, and insulation resistance stays at 50 MΩ or higher at 500 VDC. The unit weighs approximately 0.47 kg, and Keyence confirms active production status.
First, secure the KV-N24DT to a DIN rail or a flat panel using the mounting holes. Next, wire the 24 VDC supply to the power terminals and confirm correct polarity and a solid ground connection. After that, connect input devices to the 14 input terminals and load devices to the 10 output terminals, following the sink (NPN) wiring convention. Besides, leave ventilation clearance around the housing and keep signal wires apart from power cables. Finally, plug the RS-232C cable into a PC running KV STUDIO to download and test the program.
1 × Keyence KV-N24DT PLC Base Unit
1 × Terminal block cover (pre-installed)
1 × Quick start guide
1 × Mounting bracket set
Q1: What does the "D" in KV-N24DT mean?
The "D" indicates a 24 VDC supply voltage. This differs from the AC-powered KV-N24AT, KV-N24ATP, and KV-N24AR variants.
Q2: How many I/O points can the KV-N24DT support in total?
The base unit offers 14 inputs and 10 outputs. With up to 8 backplane expansion units, the system reaches 256 I/O points excluding the base unit's own I/O.
Q3: Which software programs the KV-N24DT?
Keyence KV STUDIO is the standard tool. It supports ladder editing, simulation, and program transfer over the built-in RS-232C port.
Q4: Can this PLC control two axes of motion?
Yes. The KV-N24DT provides 2-axis pulse output at up to 100 kHz, enough for simple stepper or servo positioning.
Q5: How do you ship the KV-N24DT?
We ship each unit through Fedex, UPS, or DHL. Protective foam and a sturdy carton guard the controller against transit damage.
| Brand Name | |
| Model No. | KV-N24DT |
| Product Type | Programmable Logic Controller |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
