Keyence IV-H1SN PC Software
Product Introduction
The IV-H1SN is a PC software package from Keyence for the IV family of vision sensors. It provides IV Smart Navigator for IV4 and IV3 series configuration and monitoring. Moreover, it includes IV3-Navigator, IV2-Navigator, and IV-Navigator for older sensor generations. Therefore, one license covers multiple IV platforms and simplifies fleet-wide maintenance.
Technical Specifications
The IV-H1SN runs on a standard Windows PC rather than dedicated hardware. It communicates with sensors through an Ethernet connection using 1000BASE-T speed. Furthermore, all network protocols depend on the connected sensor model. For instance, an IV4 sensor linked to an IV4-CU1 unit can expose PROFINET or EtherCAT data. However, the software itself provides no built-in ports or communication expansion.
Included software titles are IV Smart Navigator for IV4 and IV3, IV3-Navigator for IV3, IV2-Navigator for IV2, and IV-Navigator for IV. Specifically, these tools handle parameter setting, image capture, and result logging. Additionally, they support live waveform and trend monitoring during trial runs. Meanwhile, no electrical ratings, environmental limits, or physical dimensions apply, since this is pure software.
Compatibility and Setup Guide
First, confirm your sensor belongs to the IV4, IV3, IV2, or IV series. Next, install the IV-H1SN software on a PC that meets the system requirements. Then, connect the PC and sensor to the same Ethernet network. After that, launch IV Smart Navigator and search for available devices. Specifically, the software detects sensors automatically on the subnet.
For IV4 sensors, use IV Smart Navigator to set inspection parameters and network protocols. For older IV2 or IV models, select the matching navigator from the package. Finally, save your configuration and back up the settings. Besides, keep the PC and sensor on a stable network to avoid dropped connections. Always verify sensor firmware compatibility before upgrading the software.
Packaging List
FAQ
Q1: Which sensors does the IV-H1SN support?
A: It supports IV4, IV3, IV2, and IV series vision sensors.
Q2: What software is included in this package?
A: The package includes IV Smart Navigator, IV3-Navigator, IV2-Navigator, and IV-Navigator.
Q3: Does the IV-H1SN require special hardware?
A: No, it is PC software that runs on a standard Windows computer.
Q4: How does the software connect to a sensor?
A: It connects over Ethernet at 1000BASE-T speed through the sensor's network interface.
Q5: Can I configure PROFINET or EtherCAT with this software?
A: Network protocol setup depends on the connected sensor and any attached communication unit.
