Keyence IV-G150MA Sensor Head | IV-G Series

Keyence IV-G150MA Sensor Head for IV-G10 Amplifier

Product Introduction

The IV-G150MA belongs to the Keyence IV-G Series. This sensor head pairs with the IV-G10 amplifier for vision inspection tasks. It uses a narrow field of view and a monochrome CMOS image sensor. As a result, it suits precise measurement and presence detection on production lines.

Technical Specifications

The IV-G150MA provides a 1/3 inch monochrome CMOS sensor with 752 x 480 pixels. Its installed distance ranges from 40 to 150 mm. At 40 mm, the view covers 8 x 6 mm. At 150 mm, the view expands to 32 x 24 mm. Furthermore, auto focus simplifies setup across different working distances.

Illumination comes from a white LED. The lighting method supports pulse lighting and DC lighting. Users can switch between these modes as needed. Meanwhile, the sensor head draws power from the connected amplifier. It has no built-in communication ports. Instead, a dedicated cable links it to the IV-G10 amplifier.

Mechanical and Environmental Parameters

The IV-G150MA weighs approximately 75 g. It operates in temperatures from 0 to +50°C without freezing. Relative humidity must stay between 35 and 85% RH without condensation. Additionally, the IP67 rating protects the unit against dust and water ingress. This makes it reliable in harsh factory environments.

Installation Guide

First, mount the sensor head at a distance between 40 and 150 mm from the target. Next, connect the dedicated cable to the IV-G10 amplifier. Then, power on the amplifier to supply voltage to the head. After that, use the auto focus function to sharpen the image. Finally, select pulse or DC lighting based on your inspection needs.

Packaging List

1x Keyence IV-G150MA Sensor Head
1x Dedicated Connection Cable
1x Mounting Bracket
1x Instruction Sheet

FAQ

1. What amplifier works with the IV-G150MA?
The IV-G150MA connects only to the IV-G10 amplifier. It draws power and sends data through that unit.

2. What is the field of view at 150 mm?
At a 150 mm distance, the view measures 32 mm horizontally and 24 mm vertically.

3. Does the IV-G150MA include built-in communication ports?
No. The sensor head has no built-in ports. It communicates through the IV-G10 amplifier instead.

4. How does shipping work?
We ship orders by Fedex, UPS, and DHL. Delivery times vary by destination.

5. Is the IV-G150MA discontinued?
Yes. Keyence marks this model as discontinued. However, we still supply it while stock lasts.
