The Allen-Bradley 1763-MM1 provides a reliable storage solution for MicroLogix 1100 series controllers. This memory module offers 128 KB of non-volatile memory that retains data without requiring battery power. Consequently, your programs and recipes remain safe even during extended power outages.
Furthermore, the 1763-MM1 supports multiple useful functions. You can store recipe data, backup user programs, and transfer programs between different controllers. This flexibility simplifies machine setup and reduces downtime during controller replacements or upgrades.
The Allen-Bradley 1763-MM1 features 128 KB of non-volatile memory. This storage type does not rely on batteries to retain contents, eliminating the risk of data loss due to battery depletion. The module supports recipe logging, write protection, and program compare functions, giving you control over data integrity.
Additionally, this memory module supports Removal and Insertion Under Power (RIUP). You can install or remove the 1763-MM1 while the controller remains powered without causing damage. However, the system requires a power cycle or mode transition to recognize the new hardware.
Please note that the 1763-MM1 does not expand the controller's built-in memory. Instead, it serves as an external backup and transfer medium. For program compare, the module verifies whether the stored program matches the one running in the controller, providing an extra layer of safety.
The 1763-MM1 is exclusively compatible with MicroLogix 1100 series controllers. It fits into the dedicated memory slot located behind the port cover on the front of the PLC. This dedicated interface ensures reliable communication between the module and the host controller.
However, be aware that this product has reached its end-of-life status. Rockwell Automation officially discontinued the 1763-MM1 on April 1, 2022. The recommended replacement is the Micro 800 series with appropriate memory accessories. While existing units remain functional, consider future availability when planning new projects.
Installing the 1763-MM1 is a straightforward process. First, remove the port cover from the front of your MicroLogix 1100 controller. Next, align the memory module with the mounting guides inside the slot. Gently push the module inward while maintaining proper alignment.
If you feel unusual resistance during insertion, pull the module back and restart the procedure. Never force the 1763-MM1 into the slot, as this may damage both the module and the controller. The installation can be performed with power applied or removed, thanks to RIUP support.
After installation, the controller needs to recognize the new hardware. You can either cycle power, switch to program mode, or enter suspend mode. Once recognized, the 1763-MM1 becomes available for program storage, recipe logging, and transfer operations.
The Allen-Bradley 1763-MM1 complies with key environmental and safety directives. It meets EMC requirements for electromagnetic compatibility, LVD for low voltage safety, and RoHS for restriction of hazardous substances. These certifications ensure the module meets global regulatory standards.
Your shipment for the Allen-Bradley 1763-MM1 includes the following items:
One MicroLogix 1100 Memory Module (1763-MM1)
One protective cover for storage when not in use
One quick-start installation guide
Note: The host controller (MicroLogix 1100) is sold separately.
We ship all orders via FedEx, UPS, or DHL with tracking numbers provided. Standard delivery takes 3–7 business days depending on your region. Expedited shipping options are available upon request.
1. Does the 1763-MM1 increase the onboard memory of my MicroLogix 1100?
No. The Allen-Bradley 1763-MM1 does not expand the controller's built-in memory. It provides external storage for backups, recipes, and program transfers.
2. Can I install the 1763-MM1 while the controller is powered on?
Yes. The 1763-MM1 supports Removal and Insertion Under Power (RIUP). You can install or remove it without damaging the module or controller.
3. What happens if I remove the memory module after storing a program?
The program remains stored in the non-volatile memory of the 1763-MM1. You can later reinsert the module and transfer the program back to the controller.
4. Is the memory module compatible with MicroLogix 1400 controllers?
No. The 1763-MM1 is designed exclusively for MicroLogix 1100 series controllers. It does not work with MicroLogix 1400 or other controller families.
5. Why was this product discontinued, and what should I use instead?
Rockwell Automation discontinued the 1763-MM1 on April 1, 2022. The recommended replacement is the Micro 800 series with appropriate memory accessories for new installations.
| Brand Name | |
| Model No. | 1763-MM1 |
| Product Type | Memory Module |
| hasMerchantReturnPolicy | Adjust according to reality |
| Shippingdetails | Adjust according to reality |
