Upgrade Your Control System with the Schneider 171CCC76010 Processor Adapter
When your legacy Modicon Momentum system needs a reliable processor adapter, the 171CCC76010 from Schneider Electric delivers the performance and compatibility you require. This M1/M1E processor adapter is designed to integrate seamlessly into the Modicon Momentum automation platform, providing a cost-effective path to modernize your control architecture without a complete overhaul.
Key Technical Specifications
Processor: X86-based (Intel, AMD)
Clock Frequency: 32 MHz
Memory: 512 KB flash and 512 KB RAM
Program Memory: 18 kB LL984 or 240 kB IEC
Data Memory: 24 kB
Word Length: 16-bit
Communication: Modbus protocol, one non-isolated RS-232C port, one I/O bus port
Supply Voltage: 5.0 V DC ±5% (supplied by Momentum I/O base)
I/O Capacity: 8192 I/8192 O discrete, 26048 I/26048 O register
Execution Speed: 1 ms for 1,000 instructions
Operating Temperature: 0 to 60 °C (non-condensing)
Storage Temperature: -40 to 85 °C (non-condensing)
Weight: 0.093 lb (0.042 kg)
Why Choose the 171CCC76010?
This processor adapter offers a significant performance upgrade over older Momentum modules. With a 32 MHz clock and 1 ms execution time for 1,000 instructions, it handles real-time control tasks efficiently. The 512 KB memory capacity (flash and RAM) provides ample space for complex programs, while the 16-bit word length ensures compatibility with standard data handling.
Industry Applications
The 171CCC76010 is ideal for upgrading existing Modicon Momentum systems in industries such as:
Manufacturing: Replace outdated processors in assembly lines to improve throughput and reliability.
Process Control: Enhance batch processing and continuous control with faster logic execution.
Infrastructure: Modernize water treatment or HVAC systems with a dependable, Modbus-compatible adapter.
Installation & Setup Guidance
Installing the 171CCC76010 is straightforward. Simply mount the adapter onto a Momentum I/O base, which provides the 5 V DC supply. Connect the RS-232C port for programming and the I/O bus port for expansion. Ensure the ambient temperature stays within 0 to 60 °C and avoid condensation. For programming, use Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, or ProWORX 32.
Maintenance & Reliability
To maximize the lifespan of your 171CCC76010, follow these maintenance tips:
Inspect periodically: Check for dust accumulation on the enclosure and ensure proper ventilation.
Verify connections: Tighten all cable connections to prevent intermittent faults.
Monitor temperature: Keep the operating environment within the specified range to avoid overheating.
Follow manufacturer guidelines: Refer to the official Schneider Electric documentation for detailed maintenance procedures.
Compatibility & Integration
The 171CCC76010 is part of the Modicon Momentum family, ensuring compatibility with a wide range of Momentum I/O modules and bases. It communicates via Modbus protocol, making it easy to integrate with existing SCADA or HMI systems. The non-isolated RS-232C port allows direct connection to programming tools, while the I/O bus port enables expansion.
Selection Guide & Purchasing Advice
Before ordering, verify that the 171CCC76010 matches your system requirements. Check the program memory size (18 kB LL984 or 240 kB IEC) and data memory (24 kB) to ensure adequate capacity. Confirm the I/O configuration (8192 discrete I/O and 26048 register I/O) meets your application needs. For availability and lifecycle status, contact SpareTechPLC, a trusted supplier of industrial automation parts.
Comparison with Similar Modules
When compared to older Momentum processor adapters, the 171CCC76010 offers:
Higher clock speed: 32 MHz vs. typical 16 MHz in earlier models.
Larger memory: 512 KB flash/RAM vs. 128 KB in some predecessors.
Faster execution: 1 ms per 1,000 instructions vs. 2 ms or more.
Enhanced I/O capacity: Supports up to 8192 discrete I/O points.
These improvements translate to better performance and longer service life, making the 171CCC76010 a smart investment for system upgrades.
Troubleshooting & Common Issues
If you encounter communication errors, check the RS-232C cable and ensure the Modbus settings match your network. For memory errors, verify that the program size does not exceed the available capacity. If the adapter fails to power up, confirm that the I/O base supplies 5 V DC correctly. For persistent issues, consult the Schneider Electric technical support or contact SpareTechPLC for assistance.
Frequently Asked Questions
Q: What is the exact execution speed of the 171CCC76010?
A: It executes 1,000 instructions in 1 millisecond, ensuring fast response for real-time applications.
Q: Can I use this adapter with existing Momentum I/O modules?
A: Yes, it is designed for the Modicon Momentum platform and supports up to 8192 discrete I/O points.
Q: What programming software is compatible?
A: It works with Concept V2.6, Modsoft ≥ V2.5, ProWORX NxT V2.0, and ProWORX 32.
Q: Does the 171CCC76010 support Modbus communication?
A: Yes, it uses the Modbus protocol via its RS-232C port and I/O bus.
Q: What is the storage temperature range?
A: It can be stored in temperatures from -40 to 85 °C without condensation.
Ordering Information
For current availability and lifecycle status, contact SpareTechPLC. We offer competitive pricing and fast shipping for industrial automation parts. Ensure you have the correct part number 171CCC76010 when placing your order.
Attention: The above product information is sourced from the internet and cannot be guaranteed to be authentic.
For specific product parameters and prices, please contact
SpareTech PLC professionals in a timely manner.
Brand Name
Model No.
171CCC76010
Product Type
hasMerchantReturnPolicy
Adjust according to reality
Shippingdetails
Adjust according to reality
The Schneider Electric 171CCC76010 is a processor adapter module designed for the Modicon Momentum series. This compact unit operates within specified temperature limits and communicates using the Modbus protocol.Technical specifications for 171CCC76010Manufacturer Schneider ElectricProduct Type M1/M1E Processor Adapter ModuleProduct Line Modicon MomentumPart Number 171CCC76010Weight 1.00 lbs (0.45 kg)Ambient Operating Temperature 0 to 60°C (in a non-condensing environment)Clock Frequency 32 megahertzProgram Memory Capacity 18 and 240 kilobytesRated Supply Voltage 5 Volts DCCommunication Protocol Modbus protocolData Memory Capacity 4 kilobytesInput/Output Limit Processor Capacity 8,192 bits (maximum)Exact Time For 1,000 Instructions 1 millisecondMemory Type Flash memory and Random Access Memory (RAM)Memory Capacity 512 kilobytes for both flash and RAMWord Length 16 bitStorage Temperature -40 to 85°C (in a non-condensing environment)Number of Communication Ports One non-isolated RS-232C port and one Input/Output bus portDescriptionThe 171CCC76010 module from Schneider Electric is an adapter designed for M1 and M1E processors within the Modicon Momentum range. This device functions effectively in environments with temperatures varying from 0 to 60°C, provided that humidity levels do not lead to condensation. Operating with a clock frequency of 32 MHz, it supports program memory capacity options of 18 kilobytes and 240 kilobytes, making it suitable for a range of applications.Data memory capacity for this module is established at 4 kilobytes, enabling necessary data storage for operational tasks. The device is capable of handling an input/output processor limit up to 8,192 bits. Notably, it executes 1,000 instructions in precisely 1 millisecond, which is efficient for real-time applications.The module operates at a rated supply voltage of 5 VDC and utilizes flash memory along with Random Access Memory (RAM), providing a total memory capacity of 512 kilobytes. The word length for this module is standard at 16 bits, delivering compatibility with most data-handling operations.For communications, it incorporates one non-isolated RS-232C port as well as a dedicated Input/Output bus port, accommodating versatile interfacing needs. In terms of environmental resilience, it also survives storage conditions ranging from -40°C to 85°C, ensuring reliability across various settings. Weighing in at only 0.09 pounds (0.042 kilograms), this lightweight module is designed for ease of integration into control systems.Range of ProductModicon Momentum automation platformProduct or Component TypeM1/M1E processor adaptorSoftware designationConcept V2.6Modsoft >= V2.5ProWORX NxT V2.0ProWORX 32Communication Port ProtocolModbusProcessor nameX 86 based (INTEL, AMD)Clock frequency32 MHzComplementaryDiscrete I/O processor capacity8192 I/8192 OMemory Type512 KB flash512 KB RAMMemory descriptionProgram memory 18 kB LL984Program memory 240 kB IECData 24 kBMaterialLexanWord length16 bit[Us] rated supply voltage5.0 V DC +/-5 %SupplyBy Momentum I/O baseExact time for 1 Kinstruction1 msRegister I/O processor capacity26048 I/26048 OI/O limit processor capacity8192 bits maxI/O words/drop128 I/O Concept80 I/O ProWORXNumber of port1 I/O bus1 RS232C non isolatedMarkingCENet Weight0.093 lb(US) (0.042 kg)EnvironmentProtective treatmentTCAmbient Air Temperature for Operation32…140 °F (0…60 °C)Ambient Air Temperature for Storage-40…185 °F (-40…85 °C)Relative Humidity5…96 % without condensationOperating altitude6561.68 ft (2000 m)Shock resistance<= 15 gn peak 11 ms half sine wave accelerationVibration resistance0.75 mm d.a1 gnProduct CertificationsFM Class 1 Division 2ULNema type 250cULOrdering and shipping detailsCategory18206-MOMENTUM PROCESSORS,I/O BASES,CONN.Discount SchedulePC31GTIN3595860010728ReturnabilityNoCountry of originFRPacking UnitsUnit Type of Package 1PCENbr. of units in pkg.1Package 1 Height2.2 in (5.5 cm)Package 1 Width7.09 in (18 cm)Package 1 Length10.2 in (26 cm)Package weight(Lbs)7.6 oz (215 g) SpareTech PLC provides you with a PDF version of the instructions about
