IV3-G600CA Vision Sensor: Wide-Field Color AF Model Technical Guide
Product Introduction
The IV3-G600CA is a compact sensor head within the Keyence IV3 series. Specifically, it features a 1/2.9-inch color CMOS image sensor. Furthermore, this model offers a wide field of view with a 1280 × 960 pixel array. Additionally, the IV3-G600CA supports installation distances from 50 mm to 3000 mm. Consequently, the field of view ranges from 51 × 38 mm at close range to 2730 × 2044 mm at maximum distance.
Core Value
Firstly, the IV3-G600CA eliminates complex lighting and lens selection. Besides, the built-in AI function automatically configures imaging parameters. Therefore, operators achieve stable detection without specialized vision expertise. Moreover, the all-in-one design combines camera, lens, and illumination. In addition, the auto-focus capability simplifies installation significantly. Meanwhile, the IP67 rating ensures reliable operation in harsh factory environments.
Technical Insights
The IV3-G600CA employs a 1/2.9-inch color CMOS sensor with 1280 × 960 pixels. Furthermore, exposure time ranges from 12 μs to 9 ms. Besides, the white LED illumination supports both pulsed and continuous modes. Additionally, the auto-focus function activates during installation. Meanwhile, the system registers a unique focus position for each program. The housing uses die-cast zinc with an acrylic front cover. Therefore, the unit weighs approximately 75 g without the AI illumination attachment.
Installation & Maintenance
Firstly, mount the IV3-G600CA at the desired distance between 50 mm and 3000 mm. Moreover, activate the auto-focus function during initial setup. Besides, connect the sensor head to the controller using the specified FPC cable. Furthermore, configure detection programs through the IV3-Navigator software or control panel. In addition, verify the IP67 seal integrity after installation. For maintenance, clean the acrylic front cover with a soft cloth. Consequently, avoid abrasive cleaners that may damage the optical surface.
Buyer's Guide FAQ
Q1: What is the IV3-G600CA's maximum field of view?
At 3000 mm installation distance, the IV3-G600CA achieves a 2730 × 2044 mm field of view.
Q2: Does the IV3-G600CA require external lighting?
No. The IV3-G600CA includes a built-in white LED illumination unit.
Q3: What protection rating does the IV3-G600CA offer?
The IV3-G600CA provides IP67 protection when used without the polarization filter.
Q4: Can I use the IV3-G600CA at high temperatures?
Yes, the operating range is 0 to +50°C. Above 40°C, follow Keyence heat dissipation guidelines.
Q5: What communication protocols does the IV3-G600CA support?
The IV3-G600CA supports Ethernet/IP, PROFINET, TCP/IP, RS-232C, and other industrial protocols via adapters.
