IC695CPE310 PACSystems RX3i CPU Processor Installation & Maintenance
Product Introduction
The IC695CPE310 belongs to GE Fanuc's RX3i series. This programmable controller serves as the system's brain. It executes user-written logic programs efficiently. The module features a powerful 1.1 GHz Intel Celeron M processor. This CPU supports floating-point math operations. It also accommodates a large user memory. The IC695CPE310 includes one serial port for programmer connection. It also has a built-in Ethernet interface. This interface supports high-speed data exchange. The controller works with the Proficy Machine Edition software. This software enables seamless program development. The IC695CPE310 ensures smooth system start-up every time. It also maintains deterministic scan cycles. This predictability proves essential for precise machine control.
Core Value
Firstly, this controller provides substantial processing power for complex tasks. It handles demanding logic with minimal scan time. Moreover, the IC695CPE310 significantly reduces system downtime. Its diagnostic capabilities help pinpoint faults quickly. This feature allows for faster troubleshooting procedures. In addition, the module offers excellent flexibility. It integrates easily with existing RX3i racks. Furthermore, the CPU supports hot-swappable I/O modules. This support minimizes production interruptions during maintenance. Specifically, the IC695CPE310's memory retains data effectively. Power loss does not corrupt the user program. This reliability ensures continuous operational flow. Besides, the controller's communication options remain versatile. It supports both serial and Ethernet protocols simultaneously. Therefore, this controller represents a cost-effective solution. It reduces the need for multiple separate modules. Ultimately, the IC695CPE310 increases overall system value. It provides a balance of performance and affordability.
Technical Insights
The IC695CPE310 operates with a 64 MB user memory. It also includes 64 MB of non-volatile flash memory. This CPU supports up to 512 I/O points per rack. The module scans discrete I/O very quickly. It updates status within milliseconds. The processor executes standard ladder logic. It also handles structured text and function block diagrams. The built-in Ethernet port supports SRTP and Modbus TCP/IP. This feature allows easy connection to HMIs. Additionally, the serial port uses RS-232 standards. It supports SNPX and Serial I/O protocols. The IC695CPE310 also includes a real-time clock. This clock timestamps events for data logs. The controller automatically performs a self-test at power-up. It verifies both hardware and memory integrity. In case of an error, the CPU generates a fault code. You can view this code through the programmer software. Besides, the unit handles system errors gracefully. It enters a safe state to protect equipment. This CPU supports multiple program blocks. You can organize code for better maintenance. Consequently, the IC695CPE310 simplifies complex machine sequencing.
Installation & Maintenance
Begin by powering off the main system rack entirely. Then, locate an empty slot for the IC695CPE310. The CPU typically installs in the first slot. However, it can reside in any slot except the power supply. Next, align the module with the card guides. Slide the IC695CPE310 firmly into the backplane connector. Secure it by tightening the two retaining screws. After installation, connect the programming cable to the serial port. Alternatively, use the Ethernet port for faster connections. Power up the rack and observe the LED indicators. The OK LED should illuminate green. If it shows red, check the power supply first. Furthermore, ensure proper grounding for the entire chassis. Poor grounding causes erratic CPU behavior. Regularly inspect the cooling vents on the unit. Keep them clear of dust and debris. Also, periodically back up your program file. Store a copy offline for disaster recovery. When replacing a failed unit, note the firmware version. Match the firmware to ensure compatibility. Always download the application program again. This practice prevents execution errors. Proper handling extends the life of your IC695CPE310.
Buyer’s Guide FAQ
1. What is the memory size of the IC695CPE310?
The IC695CPE310 offers 64 MB of user memory and 64 MB of flash memory. It supports large-scale programs effectively.
2. Which software programs the IC695CPE310 CPU?
This CPU uses GE's Proficy Machine Edition software. You can also use older Logic Developer versions. Ensure proper software revision support.
3. Can the IC695CPE310 connect to an HMI?
Yes, it features an Ethernet port for HMI communication. It supports SRTP and Modbus TCP/IP protocols. This allows seamless operator interface integration.
4. How do I clear a fault on the IC695CPE310?
Firstly, identify the fault code via software. Correct the underlying program or hardware issue. Then, perform a clear fault command from the programmer.
5. Is the IC695CPE310 suitable for motion control?
This CPU handles coordinated motion tasks. It integrates with the RX3i motion modules. However, it does not include built-in drive outputs.
