IC200BEM003 GE Fanuc PLC Ethernet Module Installation Guide
Product Introduction
The IC200BEM003 belongs to the GE Fanuc VersaMax family. Specifically, it works as an Ethernet communication interface. This module links a VersaMax PLC to a 10/100 Mbps network. Furthermore, it handles TCP/IP and Modbus TCP protocols. Therefore, engineers use it for SCADA, HMI, and peer controller links. The unit fits directly onto the VersaMax backplane. In addition, it draws power from the rack supply. Consequently, no external power wiring is needed.
Core Value
Firstly, the IC200BEM003 cuts wiring cost. It replaces long serial runs with one Ethernet cable. Secondly, it boosts data speed. The module moves I/O data at 10/100 Mbps. Thirdly, it simplifies diagnostics. Besides, LEDs show link, activity, and fault states. Fourthly, it scales easily. Users add nodes without heavy rework. Finally, it protects legacy investments. Therefore, plants delay full system replacement.
Technical Insights
The IC200BEM003 uses a standard RJ45 port. It auto-negotiates speed and duplex. Moreover, it supports Modbus TCP server and client modes. The module holds a unique IP address. In addition, it offers configurable data mapping. Furthermore, it handles up to 128 I/O words per rack. The unit also provides a watchdog timer. Meanwhile, it reports network errors to the CPU. Besides, it tolerates 0 to 60 °C ambient heat.
Installation & Maintenance
Firstly, power down the VersaMax rack. Secondly, align the IC200BEM003 with the slot guides. Thirdly, press it firmly into the backplane. Moreover, tighten the retaining screw. Then, connect the RJ45 cable. Furthermore, set the IP address with the configuration tool. Meanwhile, verify link LEDs. For maintenance, check cable strain yearly. Besides, clean dust from the port. In addition, review error logs monthly. Therefore, keep one spare IC200BEM003 on site.
Buyer’s Guide FAQ
What does the IC200BEM003 do?
It links a VersaMax PLC rack to an Ethernet network.Which protocols does the IC200BEM003 support?
It supports Modbus TCP and standard TCP/IP traffic.Can I hot-swap the IC200BEM003?
No, you must power down the rack first.What cable type fits the IC200BEM003?
Shielded Cat5e or Cat6 Ethernet cable works best.How do I set the IC200BEM003 IP address?
Use the GE Fanuc VersaMax configuration software.
