IC695PNS001 RX3i PROFINET Master Module Installation & Maintenance
Product Introduction
The GE Fanuc IC695PNS001 provides a robust interface between the RX3i backplane and PROFINET networks. This module manages the entire PROFINET network cycle. It handles real-time (RT) and isochronous real-time (IRT) communication. You can use the IC695PNS001 to centralize control of field devices. This includes motor starters, I/O blocks, and process instruments. The module supports standard PROFINET conformance classes. It also integrates with the RX3i system seamlessly.
Core Value
Firstly, the IC695PNS001 simplifies system integration. It uses standard PROFINET protocols. You can connect to various third-party devices without custom coding. Moreover, this module reduces wiring costs. You only need a single Ethernet cable to reach remote areas. Specifically, it supports fast network reconfiguration. You can replace faulty nodes with minimal downtime. Therefore, the IC695PNS001 improves overall equipment effectiveness (OEE). Besides, it allows seamless data exchange with the RX3i CPU. This ensures precise process coordination.
Technical Insights
Firstly, the IC695PNS001 provides two Ethernet ports. These ports support an integrated switch for line topologies. You can daisy-chain multiple nodes easily. Furthermore, the module supports MRP (Media Redundancy Protocol). This offers high network availability. The module handles up to 1,500 bytes of input data. It also handles 1,500 bytes of output data. Meanwhile, it supports PROFINET V2.3 standards. The device name assignment is crucial for commissioning. You can assign names via the PAC Machine Edition software. In addition, the module features LED status indicators. These LEDs help diagnose link status and bus errors. Specifically, the "SF" and "BF" LEDs indicate system and bus faults. You can quickly trace these with the fault tables.
Installation & Maintenance
You must mount the IC695PNS001 in an RX3i Universal Backplane. Use slot 0 or 1 for optimal performance. Firstly, power off the rack before inserting the module. Secure the module with the captive screws. Afterwards, connect the PROFINET cable to port 1. This establishes the main network connection. You must use shielded Cat5e or Cat6 cables. Maintain a minimum bend radius of 25 mm for cables. Next, configure the module in the hardware configuration. You must assign an IP address to the IC695PNS001. Use a router or the software tool for this task. Always verify the device name matches the project. Regularly inspect the link LEDs. A solid green light indicates a stable connection. For maintenance, avoid hot-swapping the module. This can cause backplane damage. Periodically check firmware versions. Update the IC695PNS001 firmware to support new devices.
Buyer’s Guide FAQ
Q1: What is the GE Fanuc IC695PNS001?
The GE Fanuc IC695PNS001 is a PROFINET Scanner. It serves as a Master controller for the RX3i system. It manages communication with field devices.
Q2: What is the maximum number of devices for the IC695PNS001?
The IC695PNS001 supports up to 128 PROFINET devices. This includes both I/O and drive configurations.
Q3: Does the IC695PNS001 support IRT?
Yes, the IC695PNS001 supports Isochronous Real-Time (IRT) communication. This makes it suitable for motion control applications.
Q4: How do I assign a name to the IC695PNS001?
You assign a device name via the PROFINET DCP protocol. Use the PAC Machine Edition software for this.
Q5: What do the LEDs mean on the IC695PNS001?
The "SF" LED indicates a system fault. The "BF" LED indicates a bus or network fault. Check both during startup.
