IC695PMM335 PACSystems RX3i Motion Controller: Setup & Tuning Guide
Product Introduction
The GE Fanuc IC695PMM335 operates as a Pulse Master module. It fits into the RX3i backplane. This board generates up to 4 axes of motion control. You can use it for point-to-point positioning. Moreover, it supports trapezoidal and S-curve profiles. The IC695PMM335 connects directly to servo amplifiers. It also drives stepper motor controllers. Many packaging machines rely on this module.
Core Value
This module reduces system complexity. Firstly, it offloads motion calculations from the CPU. Therefore, the main processor handles logic faster. Moreover, the IC695PMM335 supports 2 MHz maximum output frequency. Specifically, this allows high-speed positioning applications. Besides, it provides dedicated home and limit switch inputs. These features improve machine safety and precision.
Technical Insights
The GE Fanuc IC695PMM335 uses a 5 VDC backplane supply. It includes four differential line driver outputs. Each axis also has three dedicated discrete inputs. These inputs serve home, positive limit, and negative limit functions. Furthermore, the module supports incremental encoders. You can configure electronic gearing easily. Meanwhile, the IC695PMM335 requires Proficy Machine Edition software. Use version 7.5 or higher for full compatibility.
Installation & Maintenance
Always remove backplane power before inserting the GE Fanuc IC695PMM335. First, align the module with the RX3i card guides. Then, push firmly until the connectors seat. Secure the retaining screws at top and bottom. For wiring, use shielded twisted-pair cables. Connect pulse and direction signals to your drive. Moreover, keep limit switch wires separate from power cables. Inspect the module LED annually. A steady green READY light indicates normal operation. Blinking red means a configuration error.
Buyer’s Guide FAQ
1. What systems work with the GE Fanuc IC695PMM335?
This module fits exclusively into the PACSystems RX3i backplane. It works with RX3i CPUs like IC695CPE330.
2. How many axes can the IC695PMM335 control?
The module controls up to 4 axes. Each axis requires pulse, direction, and limit signals.
3. Can I replace the IC695PMM335 with a newer model?
Yes. The IC695PMM335-AB offers the same function. Always verify firmware compatibility first.
4. What software do I need for the IC695PMM335?
You need Proficy Machine Edition. Use version 7.5 or higher. The motion block library is included.
5. Does the IC695PMM335 support closed-loop control?
Yes. It accepts incremental encoder feedback. This enables closed-loop positioning for servo axes.
