Bently Nevada 330130-070-11-00 3300 XL 8mm Probe Installation Guide
Product Introduction
The Bently Nevada 330130-070-11-00 delivers precise gap voltage readings. This 3300 XL 8mm probe senses radial vibration and axial thrust. It operates with a 5-meter probe length. This system includes a connector and cable. Moreover, it provides a linear output over a standard 2mm range. Specifically, this model meets API 670 standards for shaft monitoring. You will find this part integrates seamlessly with 3300 and 3500 monitoring racks. Besides that, it’s fully interchangeable with older 7200 series probes.
Core Value
This system provides high accuracy, reducing false machine trips. Firstly, the 330130-070-11-00 minimizes downtime with its robust design. It also extends bearing life by detecting early faults. Furthermore, this transducer offers excellent temperature stability. You will see a significant upgrade in system reliability. Therefore, the total cost of ownership remains low. In addition, the probe tip withstands harsh fluids and debris. This durability ensures your rotating assets remain safe.
Technical Insights
The Bently Nevada 330130-070-11-00 features a 7.6mm diameter probe. It uses a coaxial cable for signal integrity. Specifically, the system operates on a -24Vdc power supply. The sensitivity measures 7.87 V/mm. Meanwhile, the operating temperature range spans -35°C to +177°C. This offers excellent repeatability for critical machinery. Consequently, you can rely on this probe for API compliance. The probe's length gives you flexibility for tight installations. Moreover, remember to order the extension cable separately if needed. This ensures proper length for your rack distance.
Installation & Maintenance
Start by inspecting the threads on the Bently Nevada 330130-070-11-00. Use a gap meter to set the initial air gap. We recommend a target voltage of -10.0 Vdc during static setup. Next, torque the probe to the specified value. Please avoid twisting the cable excessively. During maintenance, check the connector for corrosion. We also suggest inspecting the probe tip for surface damage. Specifically, recalibrate the system after major overhauls. Use the reverse mounting procedure for removal. This simple approach minimizes installation errors. Always keep spare O-rings handy for the mounting adapter.
Buyer’s Guide FAQ
Q1: What is the Bently Nevada 330130-070-11-00 used for?
A: It measures radial vibration and axial displacement on rotating machinery.
Q2: Can I use the 330130-070-11-00 with a 3500 rack?
A: Yes, this probe fully integrates with the Bently Nevada 3500 monitoring system.
Q3: What is the standard cable length?
A: The 330130-070-11-00 comes with a standard 5.0 meter built-in cable.
Q4: How do I set the gap for this proximity probe?
A: Use a calibration unit to set the voltage to -10.0 Vdc at the target.
Q5: Is the 330130-070-11-00 an OEM part?
A: Yes, this is an original Bently Nevada OEM transducer part.
