330130-060-12-05 Replacement Sensor | Bently Nevada Proximitor Probe Installation Guide
Product Introduction
The Bently Nevada 330130-060-12-05 belongs to the 3300 XL 5 mm probe system family. This device measures radial vibration and axial position on rotating machinery. The system includes a probe, a Proximitor sensor, and an extension cable. Specifically, this model has a 0.6 meter probe length. It also has a 1.2 meter cable length. The connector type is a 5-pin MS connector. This assembly is a complete, calibrated system. Consequently, it offers high accuracy and stability. The 330130-060-12-05 uses eddy current technology. It provides a linear output voltage proportional to the target distance. Users commonly monitor turbines, compressors, and pumps. Furthermore, this sensor operates reliably in harsh industrial environments.
Core Value
Firstly, the 330130-060-12-05 ensures superior machine protection. It detects small changes in shaft position early. This allows for predictive maintenance scheduling. Moreover, the system offers excellent interchangeability. You do not need to recalibrate the system after replacement. This saves significant downtime. The robust design withstands high temperatures and pressure. Additionally, the non-contact measurement eliminates friction. This ensures a long operational lifespan. The probe provides a linear range of 2 mm. It has a sensitivity of 7.87 V/mm. Therefore, you get precise data for critical decision-making.
Technical Insights
This proximity probe system works with the Bently Nevada 3300 XL series. The 330130-060-12-05 has a specific part number breakdown. "330130" designates the 5 mm Proximitor probe system. "060" specifies the probe length of 0.6 meters. "12" indicates the cable length of 1.2 meters. Finally, "05" denotes the 5-pin MS connector. This system operates on a -24 Vdc power supply. It produces a negative output voltage. The target material must be AISI 4140 steel. Users must maintain a specific air gap. The standard gap is 1.27 mm (50 mils). Hence, proper mounting is crucial for accurate readings. The cable uses FEP insulation. This material offers excellent chemical resistance.
Installation & Maintenance
Proper installation ensures the 330130-060-12-05 performs well. Firstly, inspect the probe tip for damage. Clean the mounting surface thoroughly. Then, install the probe using the correct torque. Tighten the mounting nut to 6.8 Nm. Next, connect the Proximitor sensor to the extension cable. Ensure all connections are secure. You must set the initial air gap correctly. Use a micrometer to set the gap to 1.27 mm. Afterwards, measure the output voltage. It should be -10 Vdc at the standard gap. To maintain the system, inspect cables regularly. Look for any signs of wear or cuts. Additionally, check the probe face for buildup. Clean it with a soft cloth if needed. Remember to verify the calibration periodically.
Buyer's Guide FAQ
1. What is the Bently Nevada 330130-060-12-05 used for?
Specifically, the 330130-060-12-05 monitors shaft vibration and position. It protects critical turbomachinery like compressors and turbines.
2. What are the cable lengths for the 330130-060-12-05?
This model features a 0.6 meter probe length and a 1.2 meter extension cable. The total system length is 1.8 meters.
3. Can I replace an older 3300 probe with the 330130-060-12-05?
Yes, this model is a direct replacement for older 3300 series 5 mm transducers. It maintains the same performance and mounting specifications.
4. What power supply does the 330130-060-12-05 require?
The Proximitor sensor requires a -24 Vdc power supply. It outputs a negative voltage signal proportional to the gap.
5. How do I set the air gap for the 330130-060-12-05?
Set the initial air gap to 1.27 mm (50 mils) using a micrometer. Then, verify the output voltage reads -10 Vdc at this gap.
