SpareTechPLC reports that the Allen-Bradley 2094-BC02-M02-M Integrated Axis Power Module (IAM) is now available for industrial automation applications. This module delivers robust power management for multi-axis motion control systems. It combines an inverter and converter section in a single unit, simplifying system design and reducing cabinet space.
Key Features
The 2094-BC02-M02-M features a voltage rating of 400/460VAC and a nominal drive voltage range of 360-480 Volts (3 Phase). This flexibility allows it to operate in global manufacturing environments with varying power standards. The converter section outputs 15kW of power, while the inverter section provides 72 Watts, supporting demanding motion control tasks.
The module requires one control module for operation, enabling precise coordination of axis movements. Its power dissipation ranges from 36-75 Watts, ensuring efficient thermal management. The integrated design reduces wiring complexity and improves system reliability compared to separate power supply and drive configurations.
Technical Specifications
The 2094-BC02-M02-M delivers an output current of 15 A (0-pk) from the inverter section, suitable for driving servo motors in high-performance applications. The module operates within a temperature range of 32-122 F (0-50 C), making it suitable for typical industrial environments without special cooling requirements.
Physical dimensions are 4.9 x 11.9 x 13.2 inches (125 x 302 x 336 mm), and the unit weighs 13.0 lbs (5.90 kg). Installation clearance of 80 mm (3.10 in.) and a minimum enclosure depth of 302 mm (11.9 in.) ensure proper airflow and service access. The control input fuse options include FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) for overcurrent protection.
Applications
The 2094-BC02-M02-M excels in packaging machinery, where precise speed and position control are critical for high-speed wrapping, filling, and labeling operations. Its 15kW converter power supports multiple axes in a single machine, reducing component count and simplifying maintenance.
In material handling systems, such as conveyor sortation and automated storage and retrieval, the module provides reliable power distribution. The integrated design minimizes wiring errors and speeds up commissioning. The module also suits assembly lines for automotive and electronics manufacturing, where consistent torque and speed regulation improve product quality.
Availability
SpareTechPLC stocks the Allen-Bradley 2094-BC02-M02-M Integrated Axis Power Module for immediate shipment. Our inventory ensures fast delivery to minimize production downtime. Contact SpareTechPLC today for pricing and availability. Our team provides technical support to help integrate this module into your existing automation architecture.
Frequently Asked Questions
What is the lead time for the 2094-BC02-M02-M?
SpareTechPLC maintains stock of the 2094-BC02-M02-M, enabling same-day shipping for most orders. Lead time typically ranges from 1 to 3 business days depending on your location and shipping method. Contact our sales team for expedited delivery options.
Does the 2094-BC02-M02-M come with a warranty?
Yes, SpareTechPLC offers a standard one-year warranty on all Allen-Bradley products, including the 2094-BC02-M02-M. The warranty covers defects in materials and workmanship under normal operating conditions. Extended warranty options are available upon request.
What are the compatible systems for the 2094-BC02-M02-M?
The 2094-BC02-M02-M integrates with Allen-Bradley Kinetix 7000 and Kinetix 6000 multi-axis servo drive systems. It requires one control module, such as the 2094-EN02M or similar, to manage axis communication and safety functions. The module works with 360-480 Volt three-phase power supplies and supports common industrial communication protocols like SERCOS and EtherNet/IP.
