Product Summary
The Allen-Bradley 1771-HD is a handheld programming terminal for PLC-5 controllers. This device uses the Offline Development System (ODS) to modify system variables and parameter values. Operators can hold this pendant comfortably in their hands for remote use. The 25-foot cable provides ample reach from the controller module.
Expert Technical Evaluation & Performance Review
Core Architecture and Interface Design
The 1771-HD features a robust handheld design for industrial environments. It communicates directly with a servo controller module through an RS-232 port. This port uses a 9-pin D-shell connector for secure data transfer. The pendant connects to a motion controller module via the 1771-CAD cable. This setup provides a maximum extension distance of 25 cable feet (8 meters).
Operator Control and Display Functionality
This device uses specialized hard keys and soft keys for all functions. Hard keys have permanently assigned functions for consistent operation. Soft keys change their function based on the display menu. The 1771-HD display is a 4-line by 16-character layout. It shows error messages from the IMC 120 System or user-enabled menus. Operators can select from five menu displays for system management.
Power Supply and Environmental Specifications
The 1771-HD uses the 1771-CAS connector cable for its power source. It connects to AC power with a rating of 120V AC or 240V AC. The module has an operational temperature range between 0 and 60 degrees Celsius. It functions optimally within a 5-95% non-condensing relative humidity range. The pendant also offers a diagnostic test using its switch and button.
System Variable Modification and Configuration
The 1771-HD allows easy modification of system variable values through the ODS. It also permits changes to system parameter values in real-time. The five selectable menu displays include Jogs, Status, and Debug. Operators also use the File Manager and Teach Position displays. This functionality makes the 1771-HD a versatile tool for PLC-5 configuration.
Logistics & Standard Packaging Details
- One Allen-Bradley 1771-HD Handheld Teach Pendant unit.
- One 1771-CAD cable for RS-232 communication.
- One 1771-CAS connector cable for AC power connection.
- One 1771-WA wiring arm for secure cable management.
- Standard documentation for setup and operation.
Express delivery shipping is available via FedEx, UPS, and DHL.
